Electric Chain Hoists
LiftingSafety offer in our online shop a range of electric chain hoists with affordable options available to suit most budgets and applications, from many of the leading quality hoist manufacturers including Yale, Stahl, Hadef, Donati, Tractel, Verlinde, Kito and many more.
Options available on the electric chain hoists that we offer are very similar to that of the manual hand chain hoist with the addition of powered motions as opposed to requiring manual effort to raise or travel the load along a crane or runway beam.
Our quality electric hoists are fitted as standard with a top hook or lug suspension, but can also be supplied with an integrated manual or electric-powered beam trolley that can be controlled by a push button pendant or by radio remote control. Options are available with slow, fast or variable lifting speeds and hoists can be supplied to suit a variety of different voltages/power supplies with bespoke hoists also available, suitable for different environments (offshore, cleanroom, wet and/or dusty etc. IP55, IP65, IP66, high performance or high-duty for example), dependant on user requirements.
We can also offer specialist application hoists that have been specifically designed for use on wind turbines and Atex areas.
We appreciate that an electric hoist can represent a sizable investment and so if you are even a little unsure as to the most appropriate type or model, then please contact our sales or technical staff who will assist you accordingly.
Yale Electric Chain Hoists
Stahl Electric Chain Hoists
Delta Electric Chain Hoists
Liftket Electric Chain Hoists
Hadef Electric Chain Hoists & Trolley Hoists
Donati Electric Chain Hoists
GIS Electric Chain Hoists
Tractel Electric Chain Hoists
High Speed Electric Chain Hoists for Wind Turbines
Verlinde Electric Chain Hoists
Kito Electric Chain Hoists
All Electric Chain Hoists
A small and light weight (only 12kg when 3m HOL) Industrial quality electric chain hoist. Electrical protection to IP54 as standard with low voltage pendant control and overload protection. Smooth operation. Thermally protected hoist duty motor with dual braking system and rugged cast aluminium alloy hoist frame, 5:1 factor of safety yet small, compact design for industrial applications. Hardened forged steel latch-style lower hook rotates 360°.
Designed for safety and ease of use, the BatteryStar is controlled by a wireless remote to keep the operator out of the load path. The remote also features built-in intelligence, alerting the operator of an overload situation or if hoist inspection is due.
Whether you’re lifting materials at a construction site or moving equipment into place for an outdoor concert, the BatteryStar has the power and speed you need for any application – especially when external power is not available.
Capacity options available are: 250kg, 500kg, 1000kg (1 tonne), 2000kg (2 tonne), 2500kg (2.5 tonne) and 5000kg (5 tonne).
Capacity options available are: 1600kg (1.6 tonne), 2000kg (2 tonne), 2500kg (2.5 tonne), 3000kg (3 tonne), 3200kg (3.2 tonne), 4000kg (4 tonne), 5000kg (5 tonne), 7500kg (7.5 tonne) and 10000kg (10 tonne).
All CPE electric hoists can be offered with a single lifting speed or dual speed lifting (CPEF being dual speed).
All models are available with a top hook suspension point, or with a built-in, directly connected (no top hook) beam trolley that can be supplied as a manual push-pull trolley, a geared travel (hand chain driven) or electric beam trolley, which is also available with single or dual speed travel.
CMLS Single or Three Phase Hoist is a top quality electric chain hoist renowned the world over. The Lodestar is a tough, durable electric chain hoist, designed to keep working in the most arduous conditions. Features include 50% duty rating (30 minutes continuous use per hour). Overload protection and heights of lift up to 60 metres are available.
Capacity available: 250kg, 500kg, 1000kg, 2000kg and 3000kg with hook suspension or with manual trolley or electric power travel trolley.
The ST series from STAHL CraneSystems is available in 9 load capacity variants for the load capacity range from 125kg to 5,000kg. The chain hoists can be used as stationary models with suspension hook or eye, with rigid suspension or with a push trolley. Or when completed by an electric trolley they are mounted on standard cranes, off-standard cranes or in systems manufacture.
Capacity options available: 125kg, 250kg, 500kg, 1000kg, 1600kg, 2000kg, 2500kg, 3200kg & 5000kg
Suspension types: Single eye, fixed hook (non-rotating), twin eye (for fitting specifically to Liftket beam trolleys), manual push/pull beam trolley or electric beam trolley.
IP 55 Enclosure / optional IP 66, Mechanic hoist protection by current cut-off (AKS 4-8)
Zinc plated high quality RUD load chain.
Atex Certification Available.
IP 55 Enclosure / optional IP 66, Mechanic hoist protection by current cut-off (AKH 4-8)
Zinc plated high quality RUD load chain.
Atex Certification Available.
Comes as standard with Geared Travel Trolley.
IP 55 Enclosure / optional IP 66, Mechanic hoist protection by current cut-off (AKH 4-8)
Zinc plated high quality RUD load chain.
Atex Certification Available.
Comes as standard with Electric (motorised) Travel Trolley.
The Hadef EEL Big-Bag Electric Chain hoists allow for maximum lift where minimum headroom is required, the horizontal width between the hook and the hoisting unit is entirely optimal and can be tailored to suit your needs.
The DMK series electric chain hoists can be used in fixed execution (hook or eye) with hand-pushed trolley, electric trolley, trolley in low headroom configuration also in climbing execution. The high quality of Donati products is guaranteed by a Quality System Certificate UNI EN ISO 9001:2000.
Better control on long lifts: Smooth, slow speed starts and stops, fast speed for load transition. Variable frequency drive (VFD) option is also available on the Lodestar. Precision machined and hardened liftwheel: Exact fit of chain in liftwheel provides smoother operation and reduces chain vibration.
Options on 250kg Turbine Chain Hoist: Safe working load, voltage, suspension type, height of lift required (metres)
Suspension: Hook or trolley
Electro- dynamic braking eliminates heat generated by typical designs. Precision machined and hardened liftwheel: exact fit of chain in liftwheel provides smoother operation and reduces chain vibration, superior gear protection, lifetime lubricated.
Options on Wind Turbine Chain Hoist: Safe working load, trolley required, height of lift is 16 to 80 metres.
Wide range of lifting speeds:16 and 4 m/min, 24 & 6 m/min and 32 & 8 m/min, upper and lower electric limit switches
Brake clutch system: DC electromagnetic disk brake made to last as long as the hoist itself.
Hook: Upper hook (detachable) and lower hook complies with DIN standard, Motor: Thermal protection
This is a single phase electric chain hoist with a hoisting speed of 2m/min - 4m/min, Power supply 230V / 1Ph / 50HzDirect voltage control. Electric limit switch is not available on this version. Available with push travel trolley, geared travel trolley or hook suspended, 3m HOL (Height of lift as standard).
Available in sizes 80kg, 125kg, 250kg, 500kg and 1000kg.
The 3 phase standard electric chain hoist, height of lift 3m as standard. The Eurochain VL has 2 hoisting speeds and upper and lower electric limit switch. Paint 5 years guaranteed.
Comes in various ranges: Fixed hook suspension, push travel trolley, geared travel trolley and variable speed electric travel.
This hook suspended hoist with height of lift 3m as standard, 2 hoisting speeds with upper and lower electric limit switch, torque limiter and chain collector.
Various options available: hook suspended, push travel trolley and electric travel trolley.
The variable lifting speed stepless chain hoist is available with hook suspension, push travel trolley, geared travel or electric travel trolley.
Power supply 380 to 480V / 3PH / 50Hz 60Hz and low voltage control 48V (115 or 230 as option). Variable travelling speed on electric trolley (except 3 falls hoist). Motor thermal protection, Electric limit switch, Torque limiter
Available in sizes ranging from 500kg to 7500kg on request.
The electric chain hoist EUROCHAIN VL DIGICHAIN includes same equipment as standard model except: maximum height of lift 3m, hand tight positioner on push button type DIGICHAIN with 3m control cable, upper and lower electric limit switches, moveable lifting hook, low voltage control 48V on hand tight positioner with push button
Options on positioner hook hoist: Safe working load, hoist speed, suspension type.
Available in sizes 60kg, 125kg, 250kg and 500kg.
Options on Low Headroom Belt Hoist: Safe working load, HOL (Height of lift) (m), suspension type.
Very low headroom, true vertical lift. The EUROLIFT BH is specially designed for the food industry. Standard features included in basic prices: Power supply 400V / 3Ph / 50Hz, trolley with stepless speeds 5 > 20 m/min, overload limiter (110% of max. load), upper and lower limit switch, thermal protection, electrically isolated hook block and push button box.
Kito "EDC Series" Electric Chain Hoists are engineered for lightweight, fast lifting with the option to adjust the low speed. These Electric Chain Hoists are incredibly portable, they feature advanced hoist technology, are easy to service, and are built with industry-leading quality.
The New Kito "ER2 Series" Electric Chain Hoist further builds upon Kito's previous ER Series, seeking improved ease of use and superb working efficiency. To ensure safety, The hoist utilises a "double safety" mechanism that consists of a unique Friction Clutch and Upper-Lower limit switch. The control system features a fresh push-button interface and can easily be used for hours on end.
Various Options for this product are available in the form of: Hook Suspended, Push Travel Trolley, Geared Travel Trolley, Motorised Trolley, Multiple Lifting Speeds, Multiple Traversing Speeds
The Kito "EQ Series" Electric Chain Hoist is equipped with an Inverter which can change the control between mechanical and electrical, whilst keeping its conventional rigidity and high functions.
In addition to the safety functions such as the Overload Limiter, Friction Clutch and Upper-Lower limit switch, Push Buttons have been redesigned to allow prolonged use with ease.
The Kito SNER electric chain hoists are built for extreme duty applications which require a single phase power supply. Maintenance friendly features include a unique chain guide, hinged control panel, sealed housing and durable load sheave.
Options available: Custom lift lengths to suit your requirements, chain bag to keep chain clean and out of the way, plain or geared trolley mount for improved load control.
Options on Kito Electric Hoist: Model, Additional Height of Lift per Metre (3mtr as Std).
More Information About Electric Hoists
An electric hoist, with a mains powered electric motor (generally 110v, 240v or 415v AC) that utilises a chain to perform the lift, is often referred to by a more common term, an 'electric chain hoist'.
We can supply almost any type or brand of electric hoist from most major hoisting equipment manufacturers. We are also a supplier of a complete range of manual chain hoists, wire rope hoists and scaffold hoists, which could possibly prove to be a better-suited hoist for the more specific application.
Just about all of the hoists which we supply are also available with a full range of customisations and accessories to suit, which can add usability, practicality and functionality, which then, in turn, can ease the user effort required, thus increasing productivity and possibly reducing the overall production costs.
This particular type of hoisting equipment can be supplied with a variety of compatible options such as:
- 1Ph (single phase) electric - Generally 110v or 230v/240v
- 3Ph (three phase) electric - Industrial 400v/415v
- 18v DC - See the Delta DBH or the CM BatteryStar battery-powered hoist, though these are only available with 250kg, 500kg (See the Delta DBH), or 1000kg capacity (CM BatteryStar).
- Capacities range from 60kg up to 100 tonnes.
- Wide range of other unit-specific features such as twin hooks or spark resistance, alternative voltages for example.
Electric Chain Hoist Alternatives
Note: One of our electric winches may also be a more suitable lifting device, which could make lifting and handling your loads easier, more efficient, and possibly faster. Also available, which may be of interest is a wide range of air hoists, which have a more specific assortment of features, that make them more suitable for conditions such as hazardous environments or underwater (sub-sea) for example.
