Liftket "Star Speedline" Electric Chain Hoists. 125kg to 5000kg

Liftket "Star Speedline" Electric Chain Hoists. 125kg to 5000kg

400v 3ph electric chain hoists with capacity options up to 5 tonne capacity. Various suspension options. Manufactured in Germany.

Model:

STAR Speedline / LSEC-5203

Features

24V AC low voltage contactor controls (no PCB boards).
Capacities available from 125kg up to 5 tonnes
Lift heights available up to 20 metres as standard (longer on request)
Upper and lower limit switches fitted as standard on all models.
Made in Germany.

Standard Equipment on All Models

Single eye suspension
380V-415V, 50Hz, IP55
3 metre height of lift
1.5m control cable
Control pendant with emergency stop and quick change plug
Thermal protection for lifting motor
If supplied with electric trolley, the trolleys are fitted with a plug for connection to the hoist unit, for ease of installation.

Optional Accessories

Hook Suspension (non rotating)

Push Trolley Suspension (manual, push/pull)

Electric Trolley Suspension
(dual speed, 5 / 20 m/min)

Chain Bags

Specifications

Safe Working Load	ISO Classification	Chain Falls	Base Unit Model No.	Chain Size (EN818-7 - DAT) (mm)	Lifting Speeds (m/min)
125kg	M7	1	031/53	5.2x15	8/2
250kg	M6	1	031/51	5.2x15	8/2
500kg	M6	2	031/51	5.2x15	4/1
500kg	M5	1	071/54	7.2x21	8/2
1000kg	M5	2	071/54	7.2x21	4/1
1000kg	M5	1	071/55	7.2x21	6/1.5
1600kg	M5	1	091/55	9x27	8/2
2000kg	M5	2	071/55	7.2x21	3/0.75
2500kg	M5	1	111/52	11.3x31	10/2.5
3200kg	M5	2	091/55	9x27	4/1
5000kg	M5	2	111/52	11.3x31	5/1.25

Description

Features

24V AC low voltage contactor controls (no PCB boards).
Capacities available from 125kg up to 5 tonnes
Lift heights available up to 20 metres as standard (longer on request)
Upper and lower limit switches fitted as standard on all models.
Made in Germany.

Standard Equipment on All Models

Single eye suspension
380V-415V, 50Hz, IP55
3 metre height of lift
1.5m control cable
Control pendant with emergency stop and quick change plug
Thermal protection for lifting motor
If supplied with electric trolley, the trolleys are fitted with a plug for connection to the hoist unit, for ease of installation.

Optional Accessories

Hook Suspension (non rotating)

Push Trolley Suspension (manual, push/pull)

Electric Trolley Suspension
(dual speed, 5 / 20 m/min)

Chain Bags

Specifications

Safe Working Load	ISO Classification	Chain Falls	Base Unit Model No.	Chain Size (EN818-7 - DAT) (mm)	Lifting Speeds (m/min)
125kg	M7	1	031/53	5.2x15	8/2
250kg	M6	1	031/51	5.2x15	8/2
500kg	M6	2	031/51	5.2x15	4/1
500kg	M5	1	071/54	7.2x21	8/2
1000kg	M5	2	071/54	7.2x21	4/1
1000kg	M5	1	071/55	7.2x21	6/1.5
1600kg	M5	1	091/55	9x27	8/2
2000kg	M5	2	071/55	7.2x21	3/0.75
2500kg	M5	1	111/52	11.3x31	10/2.5
3200kg	M5	2	091/55	9x27	4/1
5000kg	M5	2	111/52	11.3x31	5/1.25
