Yale SC92 Beam Clamp with Shackle - Range from 1000kg to 20000kg

Yale YC92 Beam Clamp With Shackle.

Model:

Yale YC92 / BCWS-144


Description

+
  • Provides a quick and versatile rigging point for hoisting equipment, pulley blocks or loads and comes complete with a locking device and is supplied with a shackle.
  • Flexible application due to wide adjustment range.
  • The central threaded spindle allows easy attachment and a safe and secure grip.
  • To be used as a suspension point. Must NOT be used for lifting beams.
  • This clamp comes complete with shackles and is also available as a standard beam clamp (Yale YC).
  • Material specifications: Body; steel, Shackle; painted steel, Spindle and Handle; steel.

Capacity and Range

Model Capacity (SWL) Beam width (mm) Weight (kg)
YC1-S / SC92-1 1000kg 75 - 210 5
YC2-S / SC92-2 2000kg 75 - 210 6
YC3-S / SC92-3 3000kg 100 - 270 8
YC3L-S / SC92-3L 3000kg 75 - 305 9
YC5-S / SC92-5 5000kg 100 - 270 12
YC5L-S / SC92-5L 5000kg 75 - 305 12
YC10-S/L / SC92-10 10000kg 75 - 305 19
YC15-S / SC92-15 15000kg 75 - 305 35
YC20-S / SC92-20 20000kg 300 - 410 87
Pricing

+
Part N° Capacity (tonnes) Flange width/range (mm) Weight (kg) Unit Price Quantity
144-T20551
YC1-S / SC92-1 		1 tonne 75 - 210mm 5 £  116.00
144-T20552
YC2-S / SC92-2 		2 tonne 75 - 210mm 6 £  132.00
144-T20553
YC3-S / SC92-3 		3 tonne 100 - 270mm 8 £  166.00
144-T22175
YC3L-S / SC92-3L 		3 tonne 75-305mm 9 £  191.00
144-T20554
YC5-S / SC92-5 		5 tonne 100 - 270mm 12 £  245.00
144-T22176
YC5L-S / SC92-5 		5 tonne 75-305mm 12 £  299.00
144-T21254
YC10-S / SC92-10 		10 tonne 75 - 305mm 19 £  477.00
144-T22178
YC15-S / SC92-15 		15 tonne 75-305mm 35 £  778.00
144-T22177
YC20-S / SC92-20 		20 tonne 300-410mm 87 £  1697.00
Pricing Currency: Not available at the moment. Add To Quote Request   ?
  • Provides a quick and versatile rigging point for hoisting equipment, pulley blocks or loads and comes complete with a locking device and is supplied with a shackle.
  • Flexible application due to wide adjustment range.
  • The central threaded spindle allows easy attachment and a safe and secure grip.
  • To be used as a suspension point. Must NOT be used for lifting beams.
  • This clamp comes complete with shackles and is also available as a standard beam clamp (Yale YC).
  • Material specifications: Body; steel, Shackle; painted steel, Spindle and Handle; steel.

Capacity and Range

Model Capacity (SWL) Beam width (mm) Weight (kg)
YC1-S / SC92-1 1000kg 75 - 210 5
YC2-S / SC92-2 2000kg 75 - 210 6
YC3-S / SC92-3 3000kg 100 - 270 8
YC3L-S / SC92-3L 3000kg 75 - 305 9
YC5-S / SC92-5 5000kg 100 - 270 12
YC5L-S / SC92-5L 5000kg 75 - 305 12
YC10-S/L / SC92-10 10000kg 75 - 305 19
YC15-S / SC92-15 15000kg 75 - 305 35
YC20-S / SC92-20 20000kg 300 - 410 87
Part N° Capacity (tonnes) Flange width/range (mm) Weight (kg) Unit Price Quantity
144-T20551
YC1-S / SC92-1 		1 tonne 75 - 210mm 5 £  116.00
144-T20552
YC2-S / SC92-2 		2 tonne 75 - 210mm 6 £  132.00
144-T20553
YC3-S / SC92-3 		3 tonne 100 - 270mm 8 £  166.00
144-T22175
YC3L-S / SC92-3L 		3 tonne 75-305mm 9 £  191.00
144-T20554
YC5-S / SC92-5 		5 tonne 100 - 270mm 12 £  245.00
144-T22176
YC5L-S / SC92-5 		5 tonne 75-305mm 12 £  299.00
144-T21254
YC10-S / SC92-10 		10 tonne 75 - 305mm 19 £  477.00
144-T22178
YC15-S / SC92-15 		15 tonne 75-305mm 35 £  778.00
144-T22177
YC20-S / SC92-20 		20 tonne 300-410mm 87 £  1697.00
Pricing Currency: Not available at the moment. Add To Quote Request   ?
