Fork Truck Mounted Roll Forward Packaging Skip. 700 Litre to 2500 Litres - 1000kg to 1500kg

Packaging Skip, Ideal for handling rubbish of high volume, low weight material, such as paper, packaging materials etc.

Model:

PS-531


Suitable for use in a multitude of industries, these fork lift truck (FLT) tipping skips help keep working areas clear and allow safe and speedy removal of scrap or rubbish to the appropriate waste receptacle or collection point.

  • Manufactured from 3mm gauge steel.
  • Raised meshed extension sides, ideal for low weight high volume product such as cardboard.
  • Full width release handles eliminates need to lean in between the skip and truck mast.
  • Heavy duty steel under frame offering long service life properties.
  • Twin locking mechanism for added safety to ensure skip is locked if loaded unevenly.
  • Pre-drilled castor plates for retro fitment of castors (no welding required).
  • Safety security chain to ensure safe retention to FLT.
  • Bolted tipping handle for easy replacement (no welding required).
  • Ideal for handling rubbish of high volume, low weight material, such as paper, packaging materials etc.
  • Ideal for recycling areas where paper and card need to be kept separate.
  • Skips can be colour coded to adhere to stringent and environmental policies
  • Maximum Fork Section 150mm x 60mm
  • Options:
    • Auto Release Kit: Automatically tip the skip for safer operation at height (adds 130mm to overall skip height).
    • Castors: For easy manoeuvrability when FLT not in use (adds 130mm to overall skip height).
    • Drain Tap & Filter: Enables liquid to drain from skip via a protective tap in base.

Dimensions & Specifications

Roll Forward Skip With Mesh

Model No Volume Capacity (m³) Load Capacity (kg) Dimensions (mm)
A: O/A Length B: O/A Width C: O/A Height D: Bin Length E: Bin Height F: Fork Spread Weight (kg)
T12163* 0.7 1000 1360 794 1346 1197 1047 890 132
T12164 1.4 1000 1718 960 1552 1540 1250 890 188
T12165 1.9 1250 1718 1300 1552 1540 1250 890 213
T12166 2.5 1500 1718 1700 1552 1540 1250 890 237

*For T12163 model, please note the overall width is 925mm. For all other models, the bin width (dimension B) is the widest point

Part N° Capacity (m3) Capacity (kg) O/A Length (mm) O/A Width (mm) O/A Height (mm) Bin Length (mm) Bin Height (mm) Fork Spread (mm) Weight (kg) Unit Price Quantity
531-T12163 0.7 (700 litre) 1000kg 1360 794 1346 1197 1047 890 132 £ 1195.00
531-T12164 1.4 (1400 litre) 1000kg 1718 960 1552 1540 1250 890 188 £ 1345.00
531-T12165 1.9 (1900 litre) 1250kg 1718 1300 1552 1540 1250 890 213 £ 1420.00
531-T12166 2.5 (2500 litre) 1500kg 1718 1700 1552 1540 1250 890 237 £ 1855.00
Add To Quote Request   ?

Suitable for use in a multitude of industries, these fork lift truck (FLT) tipping skips help keep working areas clear and allow safe and speedy removal of scrap or rubbish to the appropriate waste receptacle or collection point.

  • Manufactured from 3mm gauge steel.
  • Raised meshed extension sides, ideal for low weight high volume product such as cardboard.
  • Full width release handles eliminates need to lean in between the skip and truck mast.
  • Heavy duty steel under frame offering long service life properties.
  • Twin locking mechanism for added safety to ensure skip is locked if loaded unevenly.
  • Pre-drilled castor plates for retro fitment of castors (no welding required).
  • Safety security chain to ensure safe retention to FLT.
  • Bolted tipping handle for easy replacement (no welding required).
  • Ideal for handling rubbish of high volume, low weight material, such as paper, packaging materials etc.
  • Ideal for recycling areas where paper and card need to be kept separate.
  • Skips can be colour coded to adhere to stringent and environmental policies
  • Maximum Fork Section 150mm x 60mm
  • Options:
    • Auto Release Kit: Automatically tip the skip for safer operation at height (adds 130mm to overall skip height).
    • Castors: For easy manoeuvrability when FLT not in use (adds 130mm to overall skip height).
    • Drain Tap & Filter: Enables liquid to drain from skip via a protective tap in base.

Dimensions & Specifications

Roll Forward Skip With Mesh

Model No Volume Capacity (m³) Load Capacity (kg) Dimensions (mm)
A: O/A Length B: O/A Width C: O/A Height D: Bin Length E: Bin Height F: Fork Spread Weight (kg)
T12163* 0.7 1000 1360 794 1346 1197 1047 890 132
T12164 1.4 1000 1718 960 1552 1540 1250 890 188
T12165 1.9 1250 1718 1300 1552 1540 1250 890 213
T12166 2.5 1500 1718 1700 1552 1540 1250 890 237

*For T12163 model, please note the overall width is 925mm. For all other models, the bin width (dimension B) is the widest point

Part N° Capacity (m3) Capacity (kg) O/A Length (mm) O/A Width (mm) O/A Height (mm) Bin Length (mm) Bin Height (mm) Fork Spread (mm) Weight (kg) Unit Price Quantity
531-T12163 0.7 (700 litre) 1000kg 1360 794 1346 1197 1047 890 132 £ 1195.00
531-T12164 1.4 (1400 litre) 1000kg 1718 960 1552 1540 1250 890 188 £ 1345.00
531-T12165 1.9 (1900 litre) 1250kg 1718 1300 1552 1540 1250 890 213 £ 1420.00
531-T12166 2.5 (2500 litre) 1500kg 1718 1700 1552 1540 1250 890 237 £ 1855.00
Add To Quote Request   ?
