Vetter 'UNI-End Buffer' Universal End Stops - To Suit Hoist Capacities up to 10t, Max. Hoist Weight 1.5t

Galvanised finish, travel limit for push trolleys and electric trolleys with flange width ranging from 91 to 300 mm and flange depths from 8 to 25mm.

Model:

UNI-End Buffer / VUB-5149


UNI end buffers by VETTER Krantechnik have been well-proven in numerous applications and are the perfect trolley limit stop for your push trolleys and electric trolleys.

Use of the clamping buffers is quite versatile and ranges from mere limitation of travel, blocking of hoists in a certain position, protection against rolling to simple absorption of impact force. UNI end buffers are installed easily and quickly and do not require any gas-cutting, welding, nor drilling. You are able to mount, position, and clamp them on the beam in no time.

Suitable for most makes of hoist with capacities of up to 10,000 kg. You can mount the multi-purpose clamping buffers on the lower or upper beam.

UNI end buffers are suitable for parallel-flanged beams of 91 to 300 mm (flange thickness of 8 to 25 mm) and are sold only in pairs (= 2 pieces).

Advantages

  • Universal trolley limit stop for parallel flanged beams (91 to 300 mm beam flange width)
  • Suitable for all makes of push trolleys and electric trolleys
  • Quick installation, without gas-cutting, welding, and drilling
  • Installed in just a few minutes
  • Multi-purpose use for installation on lower or upper beam

Technical information

Max. capacity of the hoist [kg]Max. admissible hoist weight [kg]Max. admissible trolley speed [m/min]
2,000 180 28
3,200 225 22
4,000 325 20
5,000 600 16
6,300 600 14
8,000 1,500 12
10,000 1,500 10

Scope of delivery

  • 2 galvanized and chromated sheet metal frames
  • 4 clamping brackets
  • 2 rubber buffers
  • 1 threaded rod, 370 mm
  • 1 set of nuts, washers, and safety nuts
Uni Buffer Delivery Scope

UNI end buffers by VETTER Krantechnik have been well-proven in numerous applications and are the perfect trolley limit stop for your push trolleys and electric trolleys.

Use of the clamping buffers is quite versatile and ranges from mere limitation of travel, blocking of hoists in a certain position, protection against rolling to simple absorption of impact force. UNI end buffers are installed easily and quickly and do not require any gas-cutting, welding, nor drilling. You are able to mount, position, and clamp them on the beam in no time.

Suitable for most makes of hoist with capacities of up to 10,000 kg. You can mount the multi-purpose clamping buffers on the lower or upper beam.

UNI end buffers are suitable for parallel-flanged beams of 91 to 300 mm (flange thickness of 8 to 25 mm) and are sold only in pairs (= 2 pieces).

Advantages

  • Universal trolley limit stop for parallel flanged beams (91 to 300 mm beam flange width)
  • Suitable for all makes of push trolleys and electric trolleys
  • Quick installation, without gas-cutting, welding, and drilling
  • Installed in just a few minutes
  • Multi-purpose use for installation on lower or upper beam

Technical information

Max. capacity of the hoist [kg]Max. admissible hoist weight [kg]Max. admissible trolley speed [m/min]
2,000 180 28
3,200 225 22
4,000 325 20
5,000 600 16
6,300 600 14
8,000 1,500 12
10,000 1,500 10

Scope of delivery

  • 2 galvanized and chromated sheet metal frames
  • 4 clamping brackets
  • 2 rubber buffers
  • 1 threaded rod, 370 mm
  • 1 set of nuts, washers, and safety nuts
Uni Buffer Delivery Scope

Pricing

Pack Size
Quantity
Unit Price

£189.35
