Ingersoll Rand Subsea Hydraulic Hoists

Ingersoll Rand Subsea Hydraulic Hoists

Hydraulic chain hoist, range from 6t to 50t, designed for reliable, safe underwater use, easy set up and operation

Model:

IRSH-5581

Ingersoll Rand Subsea Hydraulic Hoists

The Ingersoll Rand subsea chain hoists are designed for a full range of demanding underwater and marine applications including construction and repair, ship salvage or rig decommissioning.

Whether for commercial, military or governmental applications, the Ingersoll Rand hoists can be used everywhere from oil platforms to dam construction and mining exploration sites, saving both significant time and expense.

Designed for reliable underwater use

  • 30-meter operational depth.
  • Extremely durable construction including corrosion-resistant chain and housing and fully enclosed gear box.
  • Operates in a vertical or horizontal position.
  • Waterproof design protects all moving parts and bearings.
  • Corrosion-resistant offshore paint protection, classified C5-M (very high corrosivity - marine) per ISO 12944.

Safe operation

  • Hydraulic motor generates no bubbles that interfere with spotting operations, unlike air hoists.
  • Manifold includes overload protection and quick-down valves acting as limit switches.
  • Durable, Grade 80 zinc-plated load chain with a 5:1 safety factor.
  • Accepts up to 50 bar (750 psi) pressure in return line, and provides fluid hammer protection.

Easy to setup, handle and operate

  • Designed /supplied ready to work straight out of the box.
  • Quick disconnects on pendant hoses.
  • 100% progressive speed control delivers great spotting capabilities.
  • Pendant features large buttons for easy control with diving gloves.
  • Orbital hydraulic motor provides high torque and very precise positioning.

Specifications

Model SLH060S SLH120D SLH250D SLHSOOQ
Rated capacity, metric ton 6 12 25 so
Chain falls 1 2 2 4
Chain size (mm) 16 X 45 16 X 45 22 X 66 22 X 66
Maximum hoisting speed at rated load, m/ min (fpm) 2.8 (9.2) 1.4 (4.6) 1.0 (3.3) 0.5 (1.6)
Maximum lowering speed at rated load, m/ min (fpm) 3.0 (9.8) 1.5 (4.9) 1.1 (3.6) 0.6 (2.0)
Maximum hoisting and lowering speeds at no load, m/min (fpm) 2.8 (9.2) 1.4 (4.6) 1.0 (3.3) 0.5 (1.6)
Nominal hoisting working pressure, bar (psi)* 120 (1740) 120 135 (1950) 135 (1950)
Recommended network pressure, bar (psi)*

140 (2030)

140 (2030) 150 (2175) 150 (2175)
Nominal flow, I/min (gpm) 40 (10.6) 40 (10.6) so (13.2) so (13.2)
Pressure port size, BSPP 3/4" 3/4" 3/4" 3/4"
Return port size, BSPP 3/4" 3/4" 3/4" 3/4"
Hoist weight with 3 m of lift (kg) 185 230 555 940
Chain weight per additional meter of lift (kg) 5.7 11.4 21.4 42.8
Maximum height of lift (m) 52 49 49 24
Minimum headroom (mm) 717 945 1235 1590
Maximum water depth (m) 30 30 30 30
FEM /   150 mechanical classification 1 Bm/M3 1 Bm/M3 1 Bm/M3 1 Bm/M3
Coating system C5-M C5-M C5-M C5-M

Pricing

Unit Price Request Quote

The Ingersoll Rand subsea chain hoists are designed for a full range of demanding underwater and marine applications including construction and repair, ship salvage or rig decommissioning.

Whether for commercial, military or governmental applications, the Ingersoll Rand hoists can be used everywhere from oil platforms to dam construction and mining exploration sites, saving both significant time and expense.

Designed for reliable underwater use

  • 30-meter operational depth.
  • Extremely durable construction including corrosion-resistant chain and housing and fully enclosed gear box.
  • Operates in a vertical or horizontal position.
  • Waterproof design protects all moving parts and bearings.
  • Corrosion-resistant offshore paint protection, classified C5-M (very high corrosivity - marine) per ISO 12944.

Safe operation

  • Hydraulic motor generates no bubbles that interfere with spotting operations, unlike air hoists.
  • Manifold includes overload protection and quick-down valves acting as limit switches.
  • Durable, Grade 80 zinc-plated load chain with a 5:1 safety factor.
  • Accepts up to 50 bar (750 psi) pressure in return line, and provides fluid hammer protection.

Easy to setup, handle and operate

  • Designed /supplied ready to work straight out of the box.
  • Quick disconnects on pendant hoses.
  • 100% progressive speed control delivers great spotting capabilities.
  • Pendant features large buttons for easy control with diving gloves.
  • Orbital hydraulic motor provides high torque and very precise positioning.

Specifications

Model SLH060S SLH120D SLH250D SLHSOOQ
Rated capacity, metric ton 6 12 25 so
Chain falls 1 2 2 4
Chain size (mm) 16 X 45 16 X 45 22 X 66 22 X 66
Maximum hoisting speed at rated load, m/ min (fpm) 2.8 (9.2) 1.4 (4.6) 1.0 (3.3) 0.5 (1.6)
Maximum lowering speed at rated load, m/ min (fpm) 3.0 (9.8) 1.5 (4.9) 1.1 (3.6) 0.6 (2.0)
Maximum hoisting and lowering speeds at no load, m/min (fpm) 2.8 (9.2) 1.4 (4.6) 1.0 (3.3) 0.5 (1.6)
Nominal hoisting working pressure, bar (psi)* 120 (1740) 120 135 (1950) 135 (1950)
Recommended network pressure, bar (psi)*

140 (2030)

140 (2030) 150 (2175) 150 (2175)
Nominal flow, I/min (gpm) 40 (10.6) 40 (10.6) so (13.2) so (13.2)
Pressure port size, BSPP 3/4" 3/4" 3/4" 3/4"
Return port size, BSPP 3/4" 3/4" 3/4" 3/4"
Hoist weight with 3 m of lift (kg) 185 230 555 940
Chain weight per additional meter of lift (kg) 5.7 11.4 21.4 42.8
Maximum height of lift (m) 52 49 49 24
Minimum headroom (mm) 717 945 1235 1590
Maximum water depth (m) 30 30 30 30
FEM /   150 mechanical classification 1 Bm/M3 1 Bm/M3 1 Bm/M3 1 Bm/M3
Coating system C5-M C5-M C5-M C5-M
