Ingersoll Rand "MLK Series" Air Chain Hoists

Ingersoll Rand "MLK Series" Air Chain Hoists

IR severe duty pneumatic hoist, range from 250kg to 1000kg

Model:

IRSA-5577

Ingersoll Rand "MLK Series" Air Chain Hoists

The Ingersoll Rand MLK family of hoists is suitable for A5 / H5 severe-duty use in the 0.25 to 1 metric ton range. The MLK Series is designed to be used as a high-speed production hoist; the MLKS* is better suited for slow-speed spotting

Features

  • Range from 250kg to 1000kg.
  • 100% duty cycle. MLK/HLK are rated as HMI duty classification A5, severe duty. This equates to FEM 9.511 duty classification 2m.
  • These hoist are ideal for the harsh environments found in steel mills, foundries and electroplating operations. These are also ideal for high duty cycle applications.
  • Pull chain or pilot pendent controls provide precise spotting capabilities. For even more precise control MLKS slow speed models are available.
  • Self adjusting, air operated disc brake is spring applied and air released. Wear tested to over 1 million cycles before replacement.
  • All rotating parts are supported by either ball or roller type bearings. Unique planetary gearing system assures long life.
  • Thoughtful design includes parts interchangeability, inlet swivels, exhaust air chain lubrication, control adjustment screws and easy conversion from pull chain to pendent control.
  • Spark resistant models and a wide range of options and accessories are available.

Specifications

Model ML1000K ML1000KS ML250K ML250KR ML250KS ML500K ML500KR ML500KS
Capacity (kg) 1000 1000 250 250 250 500 500 500
Chain falls 2 2 1 1 1 1 2 1
Speed at   rated load DOWN, fpm (m/min) 46 (14.93) 33 (10.06) 117 (35.66) 38 (11.58) 90 (27.43) 97 (29.56) 20 (6.1) 66 (20.12)
Speed at   rated load UP, fpm (m/min) 28 (8.53) 11 (3.55) 101 (30.78) 26 (7.92) 40 (12.19) 55 (16.76) 13 (3.96) 22 (6.7)
Headroom (Hook Mount) (mm) 457.2 457.2 457.2 457.2 457.2 457.2 457.2 457.2
Air Consumption, m³/ min (per Hoist) 70 (1.98) 45 (1.27) 70 (1.98) 45 (1.27) 45 (1.27) 70 (1.98) 45 (1.27) 45 (1.27)
Weight @ Standard HOL (kg) 27.7 27.7 21.8 21.8 21.8 21.8 27.7 21.8

Pricing

Unit Price Request Quote
Description

The Ingersoll Rand MLK family of hoists is suitable for A5 / H5 severe-duty use in the 0.25 to 1 metric ton range. The MLK Series is designed to be used as a high-speed production hoist; the MLKS* is better suited for slow-speed spotting

Features

  • Range from 250kg to 1000kg.
  • 100% duty cycle. MLK/HLK are rated as HMI duty classification A5, severe duty. This equates to FEM 9.511 duty classification 2m.
  • These hoist are ideal for the harsh environments found in steel mills, foundries and electroplating operations. These are also ideal for high duty cycle applications.
  • Pull chain or pilot pendent controls provide precise spotting capabilities. For even more precise control MLKS slow speed models are available.
  • Self adjusting, air operated disc brake is spring applied and air released. Wear tested to over 1 million cycles before replacement.
  • All rotating parts are supported by either ball or roller type bearings. Unique planetary gearing system assures long life.
  • Thoughtful design includes parts interchangeability, inlet swivels, exhaust air chain lubrication, control adjustment screws and easy conversion from pull chain to pendent control.
  • Spark resistant models and a wide range of options and accessories are available.

Specifications

Model ML1000K ML1000KS ML250K ML250KR ML250KS ML500K ML500KR ML500KS
Capacity (kg) 1000 1000 250 250 250 500 500 500
Chain falls 2 2 1 1 1 1 2 1
Speed at   rated load DOWN, fpm (m/min) 46 (14.93) 33 (10.06) 117 (35.66) 38 (11.58) 90 (27.43) 97 (29.56) 20 (6.1) 66 (20.12)
Speed at   rated load UP, fpm (m/min) 28 (8.53) 11 (3.55) 101 (30.78) 26 (7.92) 40 (12.19) 55 (16.76) 13 (3.96) 22 (6.7)
Headroom (Hook Mount) (mm) 457.2 457.2 457.2 457.2 457.2 457.2 457.2 457.2
Air Consumption, m³/ min (per Hoist) 70 (1.98) 45 (1.27) 70 (1.98) 45 (1.27) 45 (1.27) 70 (1.98) 45 (1.27) 45 (1.27)
Weight @ Standard HOL (kg) 27.7 27.7 21.8 21.8 21.8 21.8 27.7 21.8
