Ingersoll Rand "ARO 7700" & "ARO 7790" Series Chain Hoists

Ingersoll Rand "ARO 7700" & "ARO 7790" Series Chain Hoists

IR Pneumatic Hoists, exception load control, ideal for heavy-duty industrial use, range from 125kg to 2000kg

Model:

IRAA-5573

Ingersoll Rand "ARO 7700" & "ARO 7790" Series Chain Hoists

The Ingersoll Rand 7700 and 7790 Series chain hoists have been designed specifically for heavy-duty industrial applications.

Simple, rugged and reliable, these hoists are constructed with few moving parts for easy repairs and less down.

Features

  • Range from 125kg to 2000kg
  • Meets ASME B30.16 specifications.
  • Exceptional slow-speed control provides superior spotting characteristics and ability to confidently "inch" loads into position.
  • Ideal for high duty cycles and when operating loads are near maximum capacity.
  • Powerful, self-cooling rotary motors keep hoists at peak performance at high temperatures.
  • Pendant or pull chain control responds immediately to operator's commands
  • Brake control easily adjusts to meet specific load ranges.
  • Motor and gearing provides faster lift speeds with low air consumption.
  • Compared to roller chain, link chain lasts longer, handles heavier loads and is better for high duty cycles

Specifications

Model 7718E 7756E 7770E 7776E 7790A 7792A
Capacity (kg) 275 500 125 1000 1000 2000
Chain Falls 1 1 1 2 1 2
Speed at rated load DOWN, fpm (m/min) 224 (68.3) 112 (34.1) 275 (83.8) 56 (17.1) 44 (13.4) 24 (7.3)
Speed at rated load UP, fpm (m/min) 82 (25.0) 41 (12.5) 110 (33.5) 21 (6.4) 26 (7.9) 12 (3.7)
Headroom (Hook Mount), (mm) 431.8 431.8 431.8 551.2 480.1 569
Air Consumption, m³/min (per Hoist) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98)
Weight @ Standard HOL (kg) 41 41 41 53 62 81

Pricing

Unit Price Request Quote
Description

The Ingersoll Rand 7700 and 7790 Series chain hoists have been designed specifically for heavy-duty industrial applications.

Simple, rugged and reliable, these hoists are constructed with few moving parts for easy repairs and less down.

Features

  • Range from 125kg to 2000kg
  • Meets ASME B30.16 specifications.
  • Exceptional slow-speed control provides superior spotting characteristics and ability to confidently "inch" loads into position.
  • Ideal for high duty cycles and when operating loads are near maximum capacity.
  • Powerful, self-cooling rotary motors keep hoists at peak performance at high temperatures.
  • Pendant or pull chain control responds immediately to operator's commands
  • Brake control easily adjusts to meet specific load ranges.
  • Motor and gearing provides faster lift speeds with low air consumption.
  • Compared to roller chain, link chain lasts longer, handles heavier loads and is better for high duty cycles

Specifications

Model 7718E 7756E 7770E 7776E 7790A 7792A
Capacity (kg) 275 500 125 1000 1000 2000
Chain Falls 1 1 1 2 1 2
Speed at rated load DOWN, fpm (m/min) 224 (68.3) 112 (34.1) 275 (83.8) 56 (17.1) 44 (13.4) 24 (7.3)
Speed at rated load UP, fpm (m/min) 82 (25.0) 41 (12.5) 110 (33.5) 21 (6.4) 26 (7.9) 12 (3.7)
Headroom (Hook Mount), (mm) 431.8 431.8 431.8 551.2 480.1 569
Air Consumption, m³/min (per Hoist) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98)
Weight @ Standard HOL (kg) 41 41 41 53 62 81
Contact Us About This Product
