Fall Safe FS930E Orblox 2.3m Sharp Edge Fall Arrest Block

Fall Safe FS930E Orblox 2.3m Sharp Edge Fall Arrest Block

Retractable fall arrest blocks made of stainless steel and carbon steel with high strength 19mm UHMWPE webbing and tested for use on sharp edges.

Model:

Orblox FS930E / FSFO-5584

Fall Safe FS930E Orblox 2.3m Sharp Edge Fall Arrest Block

Fall Safe FS930E Orblox Fall Safe FS930E Orblox Close Up
More from:
Fall Safe

FS930E ORBLOX is a Retractable type Fall Arrester from FALL SAFE® - smaller, lighter, stronger - tested to the latest and safest EN360:2023 standard. Engineered to meet the latest requirements and demands of the EN360 standard, this next-generation solution is built to perform in the most critical moments and toughest conditions.

ORBLOX is a 2.3m retractable fall arrester built with ultra-strong 19mm UHMWPE webbing, stainless and carbon steel. Certified to EN360:2023 and tested for sharp edge use, it's designed for one user up to 140 kg. With an integrated energy absorber, fall indicators, and a swivel top anchor for full mobility, it ensures safety without compromising freedom of movement or productivity.

It comes equipped with an energy absorber and fall indicators as well as a swivel anchor on top for greater user mobility.

Its design and internal mechanism minimise the act of braking the equipment, preventing it from braking unintentionally. This keeps the movement of users freer and more productive.

Revised in 2023, the EN360 standard redefines height protection with stricter requirements for self-retracting fall arresters. Users benefit from better protection in more diverse and harsh environments. Manufacturers have clearer guidance for testing SRLs under a wider range of conditions, with optional extended scenarios based on product use cases. EN 360:2023 modernises the standard with real-world use in mind, addressing durability, long-term reliability, and flexibility for varied work environments.

FS930E Specifications

  • Lifespan: 10 years
  • Inspections: Maximum 1 year between.
  • Maximum Load: 140kg; 50kg minimum.
  • Operating temperature range: -30°C to +50°C
  • Traceability: Serial number, RFID and QR Code
  • Conformance: CE - EN360:2023
  • Bottom connector: Auto-locking Hook (High-quality aluminium, 23kN MBS)
  • Webbing: 19mm UHMWPE webbing
  • Top Connector: 20mm auto-locking karabiner
  • Energy absorber: Double-wing shock absorber
  • Max. users: 1
  • Weight: 1.3kg

Key Features

Labelled Features

Pricing

Unit Price £345.66 Ex. VAT
Add to Shopping Basket

Please Note: Buy online is only available to UK mainland customers and addresses.

Availability

Usually 5-7 Working Days

Description

FS930E ORBLOX is a Retractable type Fall Arrester from FALL SAFE® - smaller, lighter, stronger - tested to the latest and safest EN360:2023 standard. Engineered to meet the latest requirements and demands of the EN360 standard, this next-generation solution is built to perform in the most critical moments and toughest conditions.

ORBLOX is a 2.3m retractable fall arrester built with ultra-strong 19mm UHMWPE webbing, stainless and carbon steel. Certified to EN360:2023 and tested for sharp edge use, it's designed for one user up to 140 kg. With an integrated energy absorber, fall indicators, and a swivel top anchor for full mobility, it ensures safety without compromising freedom of movement or productivity.

It comes equipped with an energy absorber and fall indicators as well as a swivel anchor on top for greater user mobility.

Its design and internal mechanism minimise the act of braking the equipment, preventing it from braking unintentionally. This keeps the movement of users freer and more productive.

Revised in 2023, the EN360 standard redefines height protection with stricter requirements for self-retracting fall arresters. Users benefit from better protection in more diverse and harsh environments. Manufacturers have clearer guidance for testing SRLs under a wider range of conditions, with optional extended scenarios based on product use cases. EN 360:2023 modernises the standard with real-world use in mind, addressing durability, long-term reliability, and flexibility for varied work environments.

FS930E Specifications

  • Lifespan: 10 years
  • Inspections: Maximum 1 year between.
  • Maximum Load: 140kg; 50kg minimum.
  • Operating temperature range: -30°C to +50°C
  • Traceability: Serial number, RFID and QR Code
  • Conformance: CE - EN360:2023
  • Bottom connector: Auto-locking Hook (High-quality aluminium, 23kN MBS)
  • Webbing: 19mm UHMWPE webbing
  • Top Connector: 20mm auto-locking karabiner
  • Energy absorber: Double-wing shock absorber
  • Max. users: 1
  • Weight: 1.3kg

Key Features

Labelled Features
