Extra Height Electric Press

Extra Height Electric Press

Electric Powered Extra Height Hydraulic Workshop Press from 40 tonne to 100 tonnes.

Model:

EHP-2561

Extra Height Electric Press

Electric Hydraulic Press
More from:
Lifting Safety Logo
Electric Hydraulic Press

The range is from 40 tonne to 100 tonne, they are designed to give a long trouble-free life in the garage workshops, agriculture, heavy plant, service and maintenance departments.

The safety overload valve is then set, the pressure gauge has an overload area indicated in red.

Features

  • Comprehensive range from 20-100 tonne.
  • Gauge positioned for easy reading, calibrated in P.S.I and BAR for accurate control when pressing
  • Work table, all presses are raised and lowered by hand winch.
  • Low pressure hydraulic system ensuring long life
  • All hydraulic rams are fitted with a stroke restrictor valve to prevent damage.
  • All pumps are fitted with a pressure releasevalve to prevent damage
  • All welded heavy-duty construction frame
  • All presses are complete with a 100mm dia. pressure guage and one pair of universal "V" Blocks.

All hydraulic cylinder piston rods are fitted with a removable end cap, the end cap is held in place by a concealed ring, this eliminates the need for external fixing screws that can interfere when using the piston rod in a confined space. The end cap is easily removed for fitting mandrels, mandrels can be manufactured to customer requirments.

Design Features

Precise guidance of the piston rod through a high quality self-lubricating guide bush ensures first class pressing.the cylinder is manufactured from top quality hydraulic tube and is an all welded construction.
Model No. O/A Frame height (mm) A Frame height (mm) B O/A Frame width (mm) C Frame width (mm) D O/A Frame depth (mm) L Min. Daylight (mm) E Max. Daylight (mm) F Side clearance between posts (mm) J Front clearance between posts (mm) K
2561-5809 2230 2030 1140 1150 800 270 1170 260 925
2561-5810 2230 2030 1560 1270 800 270 1170 260 1050
2561-5811 2230 2030 1560 1270 800 270 1170 260 1050
2561-5812 2230 2030 1560 1270 800 240 1150 260 1065
2561-5813 2230 2030 1560 1270 800 240 1150 260 1065
2561-5814 2230 2030 1560 1270 800 240 1150 260 1065
2561-5815 2230 2030 1560 1270 800 240 1150 260 1065
Part N° Press Type Capacity ( tonnes ) Ram stroke ( mm ) Pump type Guide Price (Ex. VAT) Quantity
2561-T5809 Floor 40 tonne 175 Single phase 220/240 volt 50hz Quote Required
2561-T5810 Floor 50 tonne 175 Single phase 220/240 volt 50hz Quote Required
2561-T5811 Floor 60 tonne 175 Single phase 220/240 volt 50hz Quote Required
2561-T5812 Floor 70 tonne 180 Single phase 220/240 volt 50hz Quote Required
2561-T5813 Floor 80 tonne 180 Single phase 220/240 volt 50hz Quote Required
2561-T5814 Floor 90 tonne 180 Single phase 220/240 volt 50hz Quote Required
2561-T5815 Floor 100 tonne 180 Single phase 220/240 volt 50hz Quote Required
NOTE: This item has separate transport costs (£ 60.00)
Description

Electric Hydraulic Press

The range is from 40 tonne to 100 tonne, they are designed to give a long trouble-free life in the garage workshops, agriculture, heavy plant, service and maintenance departments.

The safety overload valve is then set, the pressure gauge has an overload area indicated in red.

Features

  • Comprehensive range from 20-100 tonne.
  • Gauge positioned for easy reading, calibrated in P.S.I and BAR for accurate control when pressing
  • Work table, all presses are raised and lowered by hand winch.
  • Low pressure hydraulic system ensuring long life
  • All hydraulic rams are fitted with a stroke restrictor valve to prevent damage.
  • All pumps are fitted with a pressure releasevalve to prevent damage
  • All welded heavy-duty construction frame
  • All presses are complete with a 100mm dia. pressure guage and one pair of universal "V" Blocks.

All hydraulic cylinder piston rods are fitted with a removable end cap, the end cap is held in place by a concealed ring, this eliminates the need for external fixing screws that can interfere when using the piston rod in a confined space. The end cap is easily removed for fitting mandrels, mandrels can be manufactured to customer requirments.

Design Features

Precise guidance of the piston rod through a high quality self-lubricating guide bush ensures first class pressing.the cylinder is manufactured from top quality hydraulic tube and is an all welded construction.
Model No. O/A Frame height (mm) A Frame height (mm) B O/A Frame width (mm) C Frame width (mm) D O/A Frame depth (mm) L Min. Daylight (mm) E Max. Daylight (mm) F Side clearance between posts (mm) J Front clearance between posts (mm) K
2561-5809 2230 2030 1140 1150 800 270 1170 260 925
2561-5810 2230 2030 1560 1270 800 270 1170 260 1050
2561-5811 2230 2030 1560 1270 800 270 1170 260 1050
2561-5812 2230 2030 1560 1270 800 240 1150 260 1065
2561-5813 2230 2030 1560 1270 800 240 1150 260 1065
2561-5814 2230 2030 1560 1270 800 240 1150 260 1065
2561-5815 2230 2030 1560 1270 800 240 1150 260 1065
