Ingersoll Rand "Liftchain" Hydraulic Hoists
Hydraulic chain hoist, range from 6t to 100t, high-torque hydraulic motor, Plain, Geared or Powered Trolley options
IRHH-5580


Insersoll Rand hydraulic hoists available with 6 to 100 metric ton Lifting Capacity providing the exceptionally smooth and precise control that hydraulics offer, the LCH series of hoists are available in hook and standard, or low headroom, trolley configurations. Hydraulic motors and controls are particularly well suited for integration with complex programmable logic control (PLC) systems and other automated applications
Durability
- Rugged, compact and lightweight all steel construction adaptable for any environment.
- Grade 80 calibrated corrosion-resistant load chain with a 5:1 design factor.
- Automatic multi disc brake fully enclosed for better corrosion resistance.
- Drain holes in block prevent deterioration due to trapped water.
Safety
- Designed for explosive environments ATEX Zone 2 standard (ATEX Zone 1 package optional).
- Overload protection device ensures safe operation.
- Upper and lower limit switches integrated in hoist body provide better protection.
Performance
- Hydraulic motor offers high torque and high efficiency at low motor speed.
- Ball bearing mounted bottom hook for easier, smoother turning under load.
- External lubrication point for easier maintenance
Specifications
Model | Lifting Capacity (t) | Reeves of Chain | Headroom (mm) |
Net Weight with 3m of Chain (kg_ |
Weight per Additional Meter of Lift (kg) |
LCH060S | 6 | 1 | 735 | 93 | 5.8 |
LCH120D | 12 | 2 | 991 | 175 | 11.5 |
LCH125S | 12.5 | 1 | 865 | 500 | 10.7 |
LCH180T | 18 | 3 | 1,083 | 200 | 17.2 |
LCH2SOQ | 25 | 4 | 1,180 | 430 | 23.0 |
LC2H250D | 25 | 2 | 1,235 | 670 | 21.4 |
LC2H375T | 37.5 | 3 | 1,484 | 875 | 32.1 |
LC2HSOOQ | so | 4 | 1,590 | 950 | 42.9 |
LCH750T | 75 | 3 | 2,338 | 2,800 | 73.5 |
LCHlOOOQ | 100 | 4 | 2,455 | 3,245 | 98.0 |
Pricing
Insersoll Rand hydraulic hoists available with 6 to 100 metric ton Lifting Capacity providing the exceptionally smooth and precise control that hydraulics offer, the LCH series of hoists are available in hook and standard, or low headroom, trolley configurations. Hydraulic motors and controls are particularly well suited for integration with complex programmable logic control (PLC) systems and other automated applications
Durability
- Rugged, compact and lightweight all steel construction adaptable for any environment.
- Grade 80 calibrated corrosion-resistant load chain with a 5:1 design factor.
- Automatic multi disc brake fully enclosed for better corrosion resistance.
- Drain holes in block prevent deterioration due to trapped water.
Safety
- Designed for explosive environments ATEX Zone 2 standard (ATEX Zone 1 package optional).
- Overload protection device ensures safe operation.
- Upper and lower limit switches integrated in hoist body provide better protection.
Performance
- Hydraulic motor offers high torque and high efficiency at low motor speed.
- Ball bearing mounted bottom hook for easier, smoother turning under load.
- External lubrication point for easier maintenance
Specifications
Model | Lifting Capacity (t) | Reeves of Chain | Headroom (mm) |
Net Weight with 3m of Chain (kg_ |
Weight per Additional Meter of Lift (kg) |
LCH060S | 6 | 1 | 735 | 93 | 5.8 |
LCH120D | 12 | 2 | 991 | 175 | 11.5 |
LCH125S | 12.5 | 1 | 865 | 500 | 10.7 |
LCH180T | 18 | 3 | 1,083 | 200 | 17.2 |
LCH2SOQ | 25 | 4 | 1,180 | 430 | 23.0 |
LC2H250D | 25 | 2 | 1,235 | 670 | 21.4 |
LC2H375T | 37.5 | 3 | 1,484 | 875 | 32.1 |
LC2HSOOQ | so | 4 | 1,590 | 950 | 42.9 |
LCH750T | 75 | 3 | 2,338 | 2,800 | 73.5 |
LCHlOOOQ | 100 | 4 | 2,455 | 3,245 | 98.0 |
