Ingersoll Rand "HLK Series" Air Chain Hoists

The Ingersoll Rand HLK Series incorporates a large chain wheel to accommodate 3/8” diameter chain and a lower gear ratio to handle increased load capacities and are severe-duty rated.

• Range from 1000kg to 6000kg.
• 100% duty cycle. MLK/HLK are rated as HMI duty classification A5, severe duty. This equates to FEM 9.511 duty classification 2m.
• These hoist are ideal for the harsh environments found in steel mills, foundries and electroplating operations. These are also ideal for high duty cycle applications.
• Pull chain or pilot pendent controls provide precise spotting capabilities. For even more precise control MLKS slow speed models are available.
• Self adjusting, air operated disc brake is spring applied and air released. Wear tested to over 1 million cycles before replacement.
• All rotating parts are supported by either ball or roller type bearings. Unique planetary gearing system assures long life.
• Thoughtful design includes parts interchangeability, inlet swivels, exhaust air chain lubrication, control adjustment screws and easy conversion from pull chain to pendent control.
• Spark resistant models and a wide range of options and accessories are available.

Specifications
