Ingersoll Rand "ARO 7700" & "ARO 7790" Series ATEX Chain Hoists

Ingersoll Rand "ARO 7700" & "ARO 7790" Series ATEX Chain Hoists

IR Pneumatic Hoists, ATEX certified, range from 275kg to 1364kg

Model:

IRAS-5574

Ingersoll Rand "ARO 7700" & "ARO 7790" Series ATEX Chain Hoists

Ingersoll Rand 7700 and 7790 Series Spark Resistant Hoists meet ASME B30.16 specifications and are designed for Division 1 applications where the atmosphere contains hazardous concentrations of flammable gases, dust or other materials under normal operating conditions.

Specifically engineered for continuous heavy-duty industrial applications, these spark resistant hoists are available with a bronze top hook or a trolley adapter suspension.

Features

  • Range from 125kg to 2000kg
  • Spark resistant design
  • Stainless steel load chain and solid bronze hooks to prevent accidental sparking.
  • Zinc-plated pull chain.
  • Reduced hoist capacities and locked speed adjustments to maximize chain life.
  • Trolley models supplied with bronze wheels.
  • Optional pendant control handles with industrial-grade vinyl grip.

Division 1 Applications

  • Spark-resistant air hoists are required.
  • Atmosphere containing hazardous concentrations of flammable gases, dust or fibers, continuously, frequently or periodically, under normal operating conditions.

Division 2 Applications

  • Standard air hoists are required.
  • Atmosphere is normally non-hazardous, but contains hazardous concentrations of flammable gases, dust or fibers when a container, handling system or ventilating system fails.

Specifications

Model 7718E 7756E 7770E 7776E 7790A 7792A
Capacity (kg) 275 500 125 1000 1000 2000
Chain falls 1 1 1 2 1 2
Speed at   rated load DOWN, fpm (m/min) 224 (68.3) 112 (34.1) 275 (83.8) 56 (17.1) 44 (13.4) 24 (7.3)
Speed at   rated load UP, fpm (m/min) 82 (25.0) 41 (12.5) 110 (33.5) 21 (6.4) 26 (7.9) 12 (3.7)
Headroom (Hook Mount) (mm) 431.8 431.8 431.8 551.2 480.1 569
Air Consumption, m³/ min (per Hoist) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98)
Weight @ Standard HOL (kg) 41 41 41 53 62 81

Pricing

Unit Price Request Quote

Ingersoll Rand 7700 and 7790 Series Spark Resistant Hoists meet ASME B30.16 specifications and are designed for Division 1 applications where the atmosphere contains hazardous concentrations of flammable gases, dust or other materials under normal operating conditions.

Specifically engineered for continuous heavy-duty industrial applications, these spark resistant hoists are available with a bronze top hook or a trolley adapter suspension.

Features

  • Range from 125kg to 2000kg
  • Spark resistant design
  • Stainless steel load chain and solid bronze hooks to prevent accidental sparking.
  • Zinc-plated pull chain.
  • Reduced hoist capacities and locked speed adjustments to maximize chain life.
  • Trolley models supplied with bronze wheels.
  • Optional pendant control handles with industrial-grade vinyl grip.

Division 1 Applications

  • Spark-resistant air hoists are required.
  • Atmosphere containing hazardous concentrations of flammable gases, dust or fibers, continuously, frequently or periodically, under normal operating conditions.

Division 2 Applications

  • Standard air hoists are required.
  • Atmosphere is normally non-hazardous, but contains hazardous concentrations of flammable gases, dust or fibers when a container, handling system or ventilating system fails.

Specifications

Model 7718E 7756E 7770E 7776E 7790A 7792A
Capacity (kg) 275 500 125 1000 1000 2000
Chain falls 1 1 1 2 1 2
Speed at   rated load DOWN, fpm (m/min) 224 (68.3) 112 (34.1) 275 (83.8) 56 (17.1) 44 (13.4) 24 (7.3)
Speed at   rated load UP, fpm (m/min) 82 (25.0) 41 (12.5) 110 (33.5) 21 (6.4) 26 (7.9) 12 (3.7)
Headroom (Hook Mount) (mm) 431.8 431.8 431.8 551.2 480.1 569
Air Consumption, m³/ min (per Hoist) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98) 70 (1.98)
Weight @ Standard HOL (kg) 41 41 41 53 62 81
Contact Us About This Product
