Pfaff Proline HU TP Heavy Duty Pallet Trucks - 3000kg or 5000kg (3 Options)

Pfaff Silberblau heavy duty series pallet trucks for the handling of heavy loads with long fork option available.

Model:

HU TP / PP-3168


For the professional transportation of heavy loads.

  • Ergonomic safety control handle for one-hand operation of lifting, driving and lowering.
  • Ergonomic rubber control handle for safe handling (only model HU 30-115 TP).
  • Low maintenance high performance hydraulic pump with hard chromium plated piston and pressure relief valve
  • Frame and forks in robust steel construction, adjust-able connecting rods, especially hardened axles and the high quality powder coating ensure a long life expectancy.

Pallet Truck Specifications

Type   HU 30-115 TP HU 50-115 TP HU 50-200 TP
Lifting capacity in tonnes   3.0 5.0 5.0
Fork length in mm l 1150 1150 2000
Carrying fork width in mm 540 580 700
Fork width in mm e 160 210 210
Height when lowered in mm h¹³ 85 90 105
Lifting height in mm 115 110 110
Height of steering handle in mm h14 1200 1220 1220
Wheel size front in mm   200 x 50 200 x 50 200 x 50
Load wheel size rear in mm   82 x 70 80 x 80 80 x 80
Weight in kg   95 240 300
Pfaff Proline Heavy dims
silverline_proline_hpt_op.pdf

Pfaff SIlberblau Documentation.

Operating, safety and service instructions.
(approx. 0.7Mb)
Part N° Model Lift Capacity (kg) Fork Length (mm) Height when lowered (mm) Lifting height (mm) Weight (kg Unit Price Quantity
3168-T20335
34527128
HU 30-115 TP 3000kg 1150 85 115 95 Quote Required
3168-T20336
34527058
HU 50-115 TP 5000kg 1150 90 110 240 £  6266.00
3168-T20337
34527056
HU 50-200 TP 5000kg 2000 105 110 300 Quote Required
Pricing Currency: Not available at the moment. Add To Quote Request   ?

For the professional transportation of heavy loads.

  • Ergonomic safety control handle for one-hand operation of lifting, driving and lowering.
  • Ergonomic rubber control handle for safe handling (only model HU 30-115 TP).
  • Low maintenance high performance hydraulic pump with hard chromium plated piston and pressure relief valve
  • Frame and forks in robust steel construction, adjust-able connecting rods, especially hardened axles and the high quality powder coating ensure a long life expectancy.

Pallet Truck Specifications

Type   HU 30-115 TP HU 50-115 TP HU 50-200 TP
Lifting capacity in tonnes   3.0 5.0 5.0
Fork length in mm l 1150 1150 2000
Carrying fork width in mm 540 580 700
Fork width in mm e 160 210 210
Height when lowered in mm h¹³ 85 90 105
Lifting height in mm 115 110 110
Height of steering handle in mm h14 1200 1220 1220
Wheel size front in mm   200 x 50 200 x 50 200 x 50
Load wheel size rear in mm   82 x 70 80 x 80 80 x 80
Weight in kg   95 240 300
Pfaff Proline Heavy dims
silverline_proline_hpt_op.pdf

Pfaff SIlberblau Documentation.

Operating, safety and service instructions.
(approx. 0.7Mb)
Part N° Model Lift Capacity (kg) Fork Length (mm) Height when lowered (mm) Lifting height (mm) Weight (kg Unit Price Quantity
3168-T20335
34527128
HU 30-115 TP 3000kg 1150 85 115 95 Quote Required
3168-T20336
34527058
HU 50-115 TP 5000kg 1150 90 110 240 £  6266.00
3168-T20337
34527056
HU 50-200 TP 5000kg 2000 105 110 300 Quote Required
Pricing Currency: Not available at the moment. Add To Quote Request   ?
