Fixed Length Fork Lift Truck Carriage Mounted Easi Reach Jib with Adjustable Hook Position - Range From 200kg to 7400kg

Fixed Length Fork Lift Truck Carriage Mounted Easi Reach Jib with Adjustable Hook Position - Range From 200kg to 7400kg

Easi Reach Jib with a maximum hook reach of 1750mm. Overall length 1800mm.

Model:

ERJ-609

Jib Load Chart

Model	Last Hook Position	Overall Length	Truck Capacity at 500mm (kg) (not jib capacity - refer to load chart)	Load Centre Capacity at 500mm (kg)	Load Centre Capacity at 750mm (kg)	Load Centre Capacity at 1000mm (kg)	Load Centre Capacity at 1250mm (kg)	Load Centre Capacity at 1500mm (kg)	Load Centre Capacity at 1750mm (kg)
609-12269	1750mm	1800mm	1000	800	650	500	380	310	230
609-12270	1750mm	1800mm	1300	1000	900	630	470	380	280
609-12271	1750mm	1800mm	1500	1300	900	680	500	450	380
609-12272	1750mm	1800mm	2000	1800	1400	1100	900	720	580
609-12273	1750mm	1800mm	2500	2200	1800	1400	1100	1000	850
609-12274	1750mm	1800mm	3000	2700	2050	1450	1200	1100	900
609-12275	1750mm	1800mm	3500	3100	2500	1900	1500	1200	1000
609-12276	1750mm	1800mm	4000	3500	2700	2000	1600	1300	1100
609-12277	1750mm	1800mm	5000	4400	3400	2700	2200	1850	1400
609-12278	1750mm	1800mm	5500	5000	3650	2950	2500	2200	1850
609-12279	1750mm	1800mm	6000	5500	4050	3250	2750	2400	2050
609-12280	1750mm	1800mm	7000	6500	5400	4200	3300	2900	2400
609-12281	1750mm	1800mm	8000	7400	6150	4800	3750	3315	2750

Contact Us About This Product

If you wish to receive a quote for this product, please use the tab, this form is for general enquiries regarding this product only.

Regarding: Fixed Length Fork Lift Truck Carriage Mounted Easi Reach Jib with Adjustable Hook Position - Range From 200kg to 7400kg

Full Name: *

Email Address: *

Telephone:

Country:

Subject: *

Message: *

Attachment: - Optional
(jpg,gif,png,webp,pdf,doc,xls)

I agree to the Terms & Conditions and the Terms & Conditions of Export (if applicable). I agree to having my data stored in accordance with the Privacy Policy. I want to get exclusive email offers.

Did you know?

You can also request a quote through the pricing tab!

You can easily add more than one item to the Quote Request. This is highly recommended as we will be able to suit your needs much more efficiently.

Share this page!

Part N°	Truck Capacity (not jib capacity - refer to load chart)	Carriage Class	Last Hook Position	Overall Length	Capacity at 500mm Hook Position	Capacity at 1750mm Hook Position	Approx Weight	Centre of Gravity	Unit Price
609-T12269	1000kg	2	1750mm	1800mm	800kg	230kg	98kg	560	£1,451.24 Inc. VAT £1,209.37 Ex. VAT
609-T12270	1300kg	2	1750mm	1800mm	1000kg	280kg	98kg	560	£1,478.24 Inc. VAT £1,231.87 Ex. VAT
609-T12271	1500kg	2	1750mm	1800mm	1300kg	380kg	99kg	560	£1,518.74 Inc. VAT £1,265.62 Ex. VAT
609-T12272	2000kg	2	1750mm	1800mm	1800kg	580kg	99kg	560	Quote Required
609-T12273	2500kg	2	1750mm	1800mm	2200kg	850kg	99kg	560	Quote Required
609-T12274	3000kg	3	1750mm	1800mm	2700kg	900kg	169kg	620	Quote Required
609-T12275	3500kg	3	1750mm	1800mm	3100kg	1000kg	169kg	620	Quote Required
609-T12276	4000kg	3	1750mm	1800mm	3500kg	1100kg	170kg	620	Quote Required
609-T12277	5000kg	3	1750mm	1800mm	4400kg	1400kg	172kg	620	Quote Required
609-T12278	5500kg	4	1750mm	1800mm	5000kg	1850kg	201kg	623	£2,787.74 Inc. VAT £2,323.12 Ex. VAT
609-T12279	6000kg	4	1750mm	1800mm	5500kg	2050kg	201kg	623	£2,821.50 Inc. VAT £2,351.25 Ex. VAT
609-T12280	7000kg	4	1750mm	1800mm	6500kg	2400kg	254kg	623	Quote Required
609-T12281	8000kg	4	1750mm	1800mm	7400kg	2750kg	254kg	623	Quote Required
Availability Usually 7-10 Days

Please Note: Buy online is only available to UK mainland customers and addresses. For anywhere else, please request a quote.

Carriage mounted fork truck and telehandler jib, this Easi Reach forklift jib comes with a low beam profile to allow access in to confined spaces.

Mounted directly to the carriage of the forklift truck or telehandler, it provides the solution to converting your lift truck or telehandler into a dedicated lifting crane.

The forklift jib is 1800mm long and comes with various lifting points on the underside to allow for adjustment when handling loads of different lengths

Mounts directly onto truck carriage so forklift can be positioned closer to the load.
Multiple hook positions for flexible load handling whilst reducing handling costs.
Long jib arm to reach otherwise inaccessible places (i.e. machinery motors).
Wide carriage back plate to reduce sideways movement thus reducing damage from load swinging excessively.
'CE' marked .

Jib Load Chart

Model	Last Hook Position	Overall Length	Truck Capacity at 500mm (kg) (not jib capacity - refer to load chart)	Load Centre Capacity at 500mm (kg)	Load Centre Capacity at 750mm (kg)	Load Centre Capacity at 1000mm (kg)	Load Centre Capacity at 1250mm (kg)	Load Centre Capacity at 1500mm (kg)	Load Centre Capacity at 1750mm (kg)
609-12269	1750mm	1800mm	1000	800	650	500	380	310	230
609-12270	1750mm	1800mm	1300	1000	900	630	470	380	280
609-12271	1750mm	1800mm	1500	1300	900	680	500	450	380
609-12272	1750mm	1800mm	2000	1800	1400	1100	900	720	580
609-12273	1750mm	1800mm	2500	2200	1800	1400	1100	1000	850
609-12274	1750mm	1800mm	3000	2700	2050	1450	1200	1100	900
609-12275	1750mm	1800mm	3500	3100	2500	1900	1500	1200	1000
609-12276	1750mm	1800mm	4000	3500	2700	2000	1600	1300	1100
609-12277	1750mm	1800mm	5000	4400	3400	2700	2200	1850	1400
609-12278	1750mm	1800mm	5500	5000	3650	2950	2500	2200	1850
609-12279	1750mm	1800mm	6000	5500	4050	3250	2750	2400	2050
609-12280	1750mm	1800mm	7000	6500	5400	4200	3300	2900	2400
609-12281	1750mm	1800mm	8000	7400	6150	4800	3750	3315	2750
