Crosby A-1W Walking Load Binder, Load Restraint Tensioner - 4170kg
Model:
Crosby A-1W / WLB-2452
Crosby Walking Load Binders.
>Made of Forged steel - Quenched and Tempered. Can be used as a come-a-long for short take-up on chain. The Binder toggles away from the load.
A-1W Walking Load Binder
- Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guidelines, November 2003.
Metric Dimensions
| Model | Stock No. | Chain Size (mm) | Working Load Limit (t) | Proof Load (kN) | Ultimate Load (t) | Weight Each (kg) | Handle Length (mm) | Dimensions (mm) | |||||||
| A | B | C | D | E | F | G | |||||||||
| A-1W | 1048388 | 13 only | 4.17 | 82 | 15.0 | 5.94 | 475 | 730 | 654 | 540 | 475 | 313 | 314 | 16.0 | |
Imperial Dimensions
| Model | Stock No. | Chain Size (in.) | Working Load Limit (lbs.) | Proof Load (lbs.) | Ultimate Load (lbs.) | Weight Each (lbs.) | Handle Length (in.) | Dimensions (in.) | ||||||
| A | B | C | D | E | F | G | ||||||||
| A-1W | 1048388 | 1/2 only | 9200 | 18400 | 33000 | 13.10 | 18.69 | 28.75 | 25.75 | 21.25 | 18.69 | 12.31 | 12.38 | .63 |
As advertised in Crosby General Catalogue 2009 Page 229, and previously in Crosby General Catalogue 2006 Page 221.
Crosby-catalogue-page-number-229.pdf
(approx. 0.5Mb) Product Warnings
PDF containing all warning information relevant to the safe use of this product(approx. 0.2Mb)
