Vertical Very Hard Materials Clamp.
Model:
Crosby IPU10H & IP10H / VMC-883
More from:
IP10/H and IPU10/H vertical lifting clamps are suitable for the lifting, turning (180°) and vertical transfer of steel plates and sections with extra hard surface hardness.
These Lifting Clamps are suitable for the lifting of materials with a surface hardness up to max. 47 Rc (450HB).
These lifting clamps are fitted with a cam segment and a pivot made of extra hard wear-resistant material.
Available in two versions:
1. IPU10/H: Fitted with a hinged hoisting eye moving in all directions. Further specification: see model IPU10. For a correct use of the clamp, see fig 2 & 3.
2. IP10/H: Fitted with a fixed hoisting eye. Further specifications: see model IP10. For correct use of the clamp, see fig. 4 & 5
Higher WLL and different jaw-aperatures upon request
The minimum working load must be at least 10% of the rated WLL.
Before using the clamp always read the instruction manual supplied with the clamp
Metric Dimensions & Specifications
Model
WLL per pce(tonnes)
Dimensions (mm)
Weight per Pce
Jaw A
B
C
D
E
F
G
H
K
(kg)
With Universal Hoisting Eye
2702175
0.5
0-16
44
128
228
30
115
41
28
10
1.9
2702177
1.0
0-35
78
201
372
70
190
61
55
16
7.6
2702165
2.0
0-40
100
253
445
75
225
78
60
20
14.8
2702167
3.0
0-40
100
253
445
75
232
82
65
20
16.0
With Fixed Hoisting Eye
2702174
0.5
0-16
44
128
207
30
115
41
28
10
1.8
2702176
1.0
0-20
78
201
336
70
190
61
55
16
6.8
2702164
2.0
0-35
100
253
436
75
225
78
60
20
13.8
2702166
3.0
0-40
100
253
436
75
232
82
65
20
15.0
