Tiger 'TRE' Revovery Blocks - Inertia Reel With Retrieval Winch to EN360 and EN1496

Fall Arrest Rescue Block with Galvanised Rope. Conforms to EN 360:2002 and BS EN 1496:2017 Class B. SATRA Certified.

Model:

TRBF-5129


The Tiger Recovery Winch functions as a standard fall arrest block, but in the event of a fall, the rewind/rescue mechanism can be engaged to raise and/or lower a fallen worker. They can be mounted onto the Tiger Tripod or a davit arm for access and egress from a confined space.

Features

  • Lightweight, compact and durable.
  • Triple pawl brake system with energy dissipating mechanism.
  • .Side cable exit for smooth operation and reduced cable wear.
  • Ergonomic carrying handle makes transport, set-up and storage easy and safe.
  • Top anchor point with built-in swivel - limits lifeline twisting.
  • Supplied with screw gate karabiner for fitting to a suitable anchor point.
  • Top scaffold hook available as an option.
  • Lower self-locking snap hook and swivel with built-in impact indicator for connecting directly to the safety harness.
  • All fittings meet EN 362:2004.
  • Available with 15m or 35m wire rope lengths.
  • Complete with energy absorber.
  • Buffer spring at cable exit protects block and allows for smooth operation.
  • Easy to inspect.
  • Fully serviceable by an approved Service Agent/Centre.
  • High strength ABS (thermoplastic) casing.
  • Side case with metal bush for shaft housing.
  • 4.8mm galvanised wire rope.
  • Supplied with pull down cord.
  • Conforms to EN 360:2002 and BS EN 1496:2017 Class B.
  • PPE Regulation (EU)2016/425.
  • SATRA Certified.

Technical Data

  • Maximum rated load: 150kg.
  • Minimum static strength 12kN.
  • Braking force: less than 6kN.
  • Wire Rope - 48mm galvanised.
  • Operating Temperature: -30°C to +50°C.
  • PPE Category III Retractable Type Fall Arrestor.
Part N° Cable Length (m) Weight (kg) Guide Price Quantity
5129-T25402 15 11.8 £ 630.00
5129-T25403 30 18.6 £ 1008.00
Add To Quote Request   ?

The Tiger Recovery Winch functions as a standard fall arrest block, but in the event of a fall, the rewind/rescue mechanism can be engaged to raise and/or lower a fallen worker. They can be mounted onto the Tiger Tripod or a davit arm for access and egress from a confined space.

Features

  • Lightweight, compact and durable.
  • Triple pawl brake system with energy dissipating mechanism.
  • .Side cable exit for smooth operation and reduced cable wear.
  • Ergonomic carrying handle makes transport, set-up and storage easy and safe.
  • Top anchor point with built-in swivel - limits lifeline twisting.
  • Supplied with screw gate karabiner for fitting to a suitable anchor point.
  • Top scaffold hook available as an option.
  • Lower self-locking snap hook and swivel with built-in impact indicator for connecting directly to the safety harness.
  • All fittings meet EN 362:2004.
  • Available with 15m or 35m wire rope lengths.
  • Complete with energy absorber.
  • Buffer spring at cable exit protects block and allows for smooth operation.
  • Easy to inspect.
  • Fully serviceable by an approved Service Agent/Centre.
  • High strength ABS (thermoplastic) casing.
  • Side case with metal bush for shaft housing.
  • 4.8mm galvanised wire rope.
  • Supplied with pull down cord.
  • Conforms to EN 360:2002 and BS EN 1496:2017 Class B.
  • PPE Regulation (EU)2016/425.
  • SATRA Certified.

Technical Data

  • Maximum rated load: 150kg.
  • Minimum static strength 12kN.
  • Braking force: less than 6kN.
  • Wire Rope - 48mm galvanised.
  • Operating Temperature: -30°C to +50°C.
  • PPE Category III Retractable Type Fall Arrestor.
Part N° Cable Length (m) Weight (kg) Guide Price Quantity
5129-T25402 15 11.8 £ 630.00
5129-T25403 30 18.6 £ 1008.00
Add To Quote Request   ?
