Crosby A327 Eye Sling Hook - Range from 1590kg to 15,510kg

Crosby grade 80 alloy eye sling hook to suit chain sizes from 7mm to 22mm.

Model:

A-327 / AESH-3398


This Page has now expired. Please view our full range of Crosby Chain Hooks or Contact us with your requirements for a suitable alternative.

Crosby grade 80 (8) eye sling hooks are available with extra latch kits, the hooks are available to suit 6 different grade 8 chain sizes, these are 7mm, 10mm, 13mm, 16mm, 19mm and 22mm. The capacities of these hook range from 1590kg up to 15510kg which can make this an ideal lifting hook for a variety of lifting applications.

Features

  • Alloy Steel - Quenched and Tempered.
  • Individually Proof Tested at 2-1/2 times the Working Load Limit with certification.
  • S-4088 Latch Kit fits hooks.

Metric Specifications

* Ultimate Load is 4 times the Working Load Limit.

Chain Size (mm) A-327 Stock No. Working Load Limit (t)* Weight Each (kg) Dimensions (mm) Dimensional Drawing Replacement Latch Stock No.
A B D E F G R
7 1003764 1.59 0.36 34 14.2 88 36.6 44.7 22.9 94.5 1090250
10 1003773 3.22 0.95 46.2 19.1 116 45.2 56.9 31.8 123 1090251
13 1003782 5.45 1.68 57.5 23.9 140 53.8 63.5 39.4 144 1090252
16 1003791 8.21 2.9 70 29.2 165 61.2 73.2 47.8 168 1090253
19 1003808 12.84 4.45 83 34 187 68.3 83 55 194 1090254
22 1003817 15.51 7 94.5 36.6 215 77.7 92 62.2 217 1090255

Imperial Specifications

* Ultimate Load is 4 times the Working Load Limit.

Chain Size (in.) A-327 Stock No. Working Load Limit (lbs.)* Weight Each (lbs.) Dimensions (in.) Dimensional Drawing Replacement Latch Stock No.
A B D E F G R
9/32 (1/4)  1003764 3500 0.81 1.34 0.56 3.47 1.44 1.76 0.9 3.72 1090250
3/8 1003773 7100 2.1 1.82 0.75 4.56 1.78 2.24 1.25 4.83 1090251
1/2 1003782 12000 3.71 2.26 0.94 5.5 2.12 2.5 1.55 5.67 1090252
5/8 1003791 18100 6.4 2.75 1.15 6.5 2.41 2.88 1.88 6.61 1090253
3/4 1003808 28300 9.8 3.26 1.34 7.36 2.69 3.27 2.16 7.64 1090254
7/8 1003817 34200 15.4 3.72 1.44 8.48 3.06 3.62 2.45 8.56 1090255

Unfortunately this product has been discontinued and/or is no longer available. Please contact us for details on possible alternative products.

This Page has now expired. Please view our full range of Crosby Chain Hooks or Contact us with your requirements for a suitable alternative.

Crosby grade 80 (8) eye sling hooks are available with extra latch kits, the hooks are available to suit 6 different grade 8 chain sizes, these are 7mm, 10mm, 13mm, 16mm, 19mm and 22mm. The capacities of these hook range from 1590kg up to 15510kg which can make this an ideal lifting hook for a variety of lifting applications.

Features

  • Alloy Steel - Quenched and Tempered.
  • Individually Proof Tested at 2-1/2 times the Working Load Limit with certification.
  • S-4088 Latch Kit fits hooks.

Metric Specifications

* Ultimate Load is 4 times the Working Load Limit.

Chain Size (mm) A-327 Stock No. Working Load Limit (t)* Weight Each (kg) Dimensions (mm) Dimensional Drawing Replacement Latch Stock No.
A B D E F G R
7 1003764 1.59 0.36 34 14.2 88 36.6 44.7 22.9 94.5 1090250
10 1003773 3.22 0.95 46.2 19.1 116 45.2 56.9 31.8 123 1090251
13 1003782 5.45 1.68 57.5 23.9 140 53.8 63.5 39.4 144 1090252
16 1003791 8.21 2.9 70 29.2 165 61.2 73.2 47.8 168 1090253
19 1003808 12.84 4.45 83 34 187 68.3 83 55 194 1090254
22 1003817 15.51 7 94.5 36.6 215 77.7 92 62.2 217 1090255

Imperial Specifications

* Ultimate Load is 4 times the Working Load Limit.

Chain Size (in.) A-327 Stock No. Working Load Limit (lbs.)* Weight Each (lbs.) Dimensions (in.) Dimensional Drawing Replacement Latch Stock No.
A B D E F G R
9/32 (1/4)  1003764 3500 0.81 1.34 0.56 3.47 1.44 1.76 0.9 3.72 1090250
3/8 1003773 7100 2.1 1.82 0.75 4.56 1.78 2.24 1.25 4.83 1090251
1/2 1003782 12000 3.71 2.26 0.94 5.5 2.12 2.5 1.55 5.67 1090252
5/8 1003791 18100 6.4 2.75 1.15 6.5 2.41 2.88 1.88 6.61 1090253
3/4 1003808 28300 9.8 3.26 1.34 7.36 2.69 3.27 2.16 7.64 1090254
7/8 1003817 34200 15.4 3.72 1.44 8.48 3.06 3.62 2.45 8.56 1090255

Unfortunately this product has been discontinued and/or is no longer available. Please contact us for details on possible alternative products.
