Load cell manufactured for use in subsea or submersible projects.
Quick Ref:
SS-5661
Crosby Straightpoint Subsea link (SL) has been manufactured for use in subsea or submersible projects where accurate load monitoring is required.
Constructed from 17-4PH stainless steel with o’ring seals and moulded SubConn connector the SL link design ensures high integrity and will resist saltwater, temperature variations and the water pressure at varying depths of up to 2000m or 6562 feet.
At depth the SL can be handled and rigged via an ROV where it maybe inaccessible by a diver/s or cost may prohibit.
Output options include mV/V to the Crosby Straightpoint Handheld plus, 4-20mA or 0-10v analogue to a PLC, Datalogger or The Multi Operation Survey System (MOSS), RS485 or an integral datalogger storing up to one million readings and powered by an internal battery.
Designed to accept Crosby ROV shackles – additionally there is an option for ROV mounting on the SL body itself.
Features
Manufactured for use in subsea or submersible projects.
On board data-logging option.
Pressure tested to depth of 2,000 m.
SubConn connector.
Environmental protection IP68/NEMA6P.
Constructed from 17-4PH stainless steel.
Designed to fit with The Crosby Group ROV shackles.
Option for ROV mounting on the SL body itself.
Design Factor: 5:1
Operating Temperature: -10°C to +50°C.
Accuracy: ±0.1% of full scale.
Max depth of use: 2,000 m.
Material: 17-4 PH Stainless steel.
MTBF to WLL: Typically 50 million cycles.
Elongation: Typically <0.4mm / at WLL.
Output: Options for: mV/V / 4-20mA / 0-10v / RS485 or internal data logger.
Output options include mV/V to the Crosby SP Handheld Plus, 4-20mA or 0-10v analogue to a PLC, data-logger or The Multi Operation Survey System (MOSS), RS485 or an integral data- logger storing up to one million readings and powered by an internal battery.
Dimensions & Specifications
Stock No.
Model
Capacity (t)
Weight (kg)
Dimensions (mm)
Crosby Shackle
A
B
C
D
ØE
F
2789352
SL6T5
6.5
7
95
240
180
25
30
73
G2130
1019533
2789353
SL12T
12
10
100
300
200
40
40
88
G2130
1019597
2789354
SL25T
25
16
130
350
230
45
55
93
G2130
1019659
2789355
SL35T
35
22
150
400
250
50
60
98
G2130
1019677
2789356
SL55T
55
34
168
450
260
65
75
113
G2130
1021156
2789357
SL85T
85
46
190
490
290
75
88
123
G2130
1021174
2789358
SL120T
120
67
220
550
335
86
100
134
G2140
1021192
