The TIMH range is a Wireless Running Line Tensiometer or RLTM built with dockside, marine, offshore, towage and salvage applications in mind. It is particularly useful when there is no anchor or dead end on the line to rig an SP Radiolink or Loadlink digital dynamometer. It measures tension force at speeds up to 20m/min or 65ft/min.
Two versions of the TIMH are available:
- Long range 2.4GHz version providing industry leading wireless range of 700m or 2300ft to SP’s SW-HHP handheld or software options.
- Bluetooth output and can be connected to any smart phone running SP’s free HHP app on iOS or Android at ranges up to 100m or 328ft.
The TIMH is constructed from marine grade stainless steel and is suitable for many wire rope configurations up to 150t and will, as an option, calculate lineout and speed. The TIMH has several mounting points featured in its unique design but if other mounting options are required, Straightpoint can provide a custom engineered solution specific to your application.
Available as a wireless or cabled system, utilizing Straightpoint’s HHP range of handheld displays or SW-MWLC software, this impressive Running Line Dynamometer or RLTM is available to ship from stock, to anywhere in the world, within days.
Features
- Fully constructed from corrosion-resistant stainless steel.
- Large range of capacities to 150t and wire rope diameters up 89mm.
- Measures tension force at speeds up to 20m/min.
- Five-wheel design, improving accuracy.
- Maintenance-free heavy duty bushes.
- Options for lineout and speed available.
- Software available to data log and monitor or analogue outputs.
- Cabled system or wireless bluetooth option are available and is supplied with a free HHP app for iOS and Android.
- IP67 or NEMA6 Loadpin.
- Design validated by FEA.
- Battery Type: 4 x AA Alkaline.
- Battery Life: Wireless version 1,200 hours continuous.
- Operating Temperature: -10°C to +50°C.
- Accuracy: ±2% of full scale.
- Frequency: 2.4 GHz.
- System Range (max): 700 m.
- Data Rate: 3 updates per second.
- Line out and speed: via SW-MWLC software.
Dimensions & Specifications
| Stock No. |
Model |
Capacity (t) |
Resolution (t) |
Rope Dia. (mm) |
Weight (kg) |
Max. Speed
(m per min)
|
Dimensions (mm) |
| Min. |
Max. |
A |
B |
C |
D |
| 2789054 |
MTIMH10TRD |
10 |
0.01 |
4 |
19 |
9 |
50 |
422 |
328 |
152 |
36 |
| 2789136 |
TIMH10TRD |
10 |
0.01 |
13 |
19 |
90 |
20 |
865 |
674 |
329 |
111 |
| 2789139 |
TIMH25TRD |
25 |
0.02 |
16 |
26 |
86 |
20 |
865 |
674 |
329 |
111 |
| 2789144 |
TIMH56TRD |
56 |
0.05 |
28 |
38 |
81 |
20 |
865 |
674 |
329 |
111 |
| 2789146 |
TIMH80TRD |
80 |
0.1 |
40 |
52 |
76 |
20 |
865 |
674 |
329 |
111 |
| 2789270 |
TIMH150TRD |
150 |
0.2 |
52 |
89 |
230 |
20 |
1250 |
1050 |
416 |
153 |
