Multi-Sec Adjustable H-Frame Lifting Beam

Adjustable Lifting Frame for Heavy-Duty Applications: Capacity Options Up to 15 Tonnes

The Multisec Adjustable H-Frame is a versatile adjustable lifting frame designed for heavy-duty lifting applications where load dimensions, lifting centres and handling requirements can vary. Its adaptable design makes it suitable for low-headroom lifting, large loads and irregularly shaped equipment where a fixed lifting frame may not provide the flexibility required.

Available in 3, 5, 10 and 15 tonne Working Load Limit (WLL) options, the adjustable H-frame can be configured to suit a wide range of lifting applications. Both the main beam and transverse beams can be adjusted to accommodate different load dimensions, allowing the same lifting frame to be used across multiple lifting operations.

Adjustable H-Frame Lifting Beam Configuration

Unlike a fixed lifting frame designed around a specific load geometry, the Multisec Adjustable H-Frame can be adjusted in both length and width. The main beams can be adjusted from 1.5m to 6m (model dependent), while the transverse beams provide adjustment from 1m to 4m (model dependent). This allows the lifting points and overall frame dimensions to be configured to suit the load being handled.

Heavy-Duty Adjustable Lifting Frame

The flexibility of the adjustable lifting frame makes it suitable for a variety of demanding applications, including lifting fabricated structures, equipment skids, machinery, precast concrete units and irregular or oversized loads. The ability to change the frame configuration between lifts provides a practical alternative to using multiple fixed lifting frames for different load sizes.

Designed for heavy lifting and low-headroom applications, the Multisec Adjustable H-Frame provides a flexible lifting solution where load dimensions and lifting arrangements are not consistent from one operation to the next. The range of WLL options and extensive beam adjustment make it suitable for a wide variety of industrial lifting and handling requirements.

Key Features

• Adjustable Lifting Geometry - Length and width adjustment allows the frame to suit different load sizes and lifting centres without requiring multiple fixed lifting frames.
• Stable Load Handling - The H-Frame arrangement provides enhanced stability when handling wider, longer or irregular loads where a conventional lifting beam may not be suitable.
• Certified Lifting Performance - UK-manufactured and designed to BS EN 13155, delivering reliable lifting performance across demanding industrial applications.
• Built For Loads That Change From Project To Project
• 3-15t WLL (working load limit) capacity options
• Adjustable both on the main beam and the cross beams
• Lengths up to 6 metres and widths up to 4 metres.
• Low-Profile, Low-Headroom Design
• Fitted with 4 lifting shackles and swivel hooks with standard latches. Alternative fittings are available on request.
• Custom designs, lengths, widths and capacities are available on request.
• Designed and manufactured in accordance with BS EN 13155
