Yoke 271 Metric Ball Bearing Swivel Lifting Point

Yoke 271 Metric Ball Bearing Swivel Lifting Point

Metric thread ball bearing swivel hoist with with pivoting link. M8 to M90 thread sizes. 400kg to 40 tonne WLL.

Model:

8-271

Quick Ref:

YBBS-5644

Yoke 271 Metric Ball Bearing Swivel Lifting Point

Yoke 271 Metric Digital Swivel Point - Angled Yoke 271 Metric Digital Swivel Point - Front
More from:
Yoke

Yoke Rotating Lifting Eye with Ball Bearing Swivel - Metric

The Yoke 271 lifting point is a premium swivel lifting point designed to deliver maximum flexibility and safety in demanding lifting applications. Featuring a high-quality ball bearing mechanism, this bearing swivel lifting point allows smooth 360° rotation and wide-angle pivoting, ensuring the lifting ring naturally aligns with the direction of pull. This intelligent movement reduces the risk of dangerous side loading, making the Yoke 271 lifting point an ideal choice for complex or multi-directional lifting operations.

Engineered from high-strength, quenched and tempered alloy steel, this swivel lifting point is built for durability and consistent performance under heavy loads. The Yoke 271 lifting point is proof tested and fatigue rated, providing long-term reliability even in repetitive lifting environments. As a robust bearing swivel lifting point, it offers both strength and precision, making it a trusted solution for professional lifting and lashing tasks where safety and efficiency are paramount.

Key Features: 8-271 Lifting Point from Yoke

  • Pivots to 230°, rotates through 360° due to its unique ball bearing design
  • Manufactured from forged alloy steel, quenched and tempered
  • Tested in accordance with EN1677-4
  • Certified by DGUV GS-OA-15-04
  • Load-rated parts are 100% magnaflux crack detected
  • Individual forged parts and batch code links to the Test Certificate sheet
  • Bolts are Metric thread
  • Proof tested to 2.5 times the WLL
  • Fatigue rated to 20,000 cycles at 1.5 times the WLL
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26
  • Easy to attach or dismantle due to the forged hexagon-shaped body of the Swivel Point
  • Capable of rotating under load. Do not turn continuously in a 90-degree direction at full load

Certification

Each unit comes fully certified with a test certificate or an EC Declaration of Conformity stating compliance with the essential health and safety requirements of the Machinery Directive 2006/42/EC, the Supply of Machinery (Safety) Regulations 2008 and Section 6 of the Health and Safety at Work Etc Act 1974.

Manufactured and tested in accordance with EN1677-1. All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.

Technical Specifications

Item NO.  Working Load Limit Thread version Dimensions (mm) Torque Weight
M E (mm) Pitch DIN13 A B C D F G H K Nm kg
8-271-003 0.4 tonnes M8 12 1.25 29 32 40 8 72 35 16 30 10 0.2
8-271-004 0.6 tonnes M10 15 1.5 29 32 40 8 72 35 16 30 10 0.2
8-271-006 0.7 tonnes M12 18 1.75 35 50 45 10 95 40 18 36 10 0.3
8-271-013 1.5 tonnes M16 24 2 36 50 54 13 104 46 22 41 30 0.5
8-271-020 2.5 tonnes M20 30 2.5 36 54 68 13 122 62 29 55 70 1
8-271-035 4 tonne M24 36 3 41 66 88 19 154 78 36 70 150 2.2
8-271-060 6 tonne M30 45 3.5 50 86 120 22 206 90 48 80 350 4.5
8-271-080 10 tonne M36 54 4 50 86 120 22 206 90 48 80 410 4.6
8-271-120 13 tonne M42 63 4.5 67 110 122 25 235 98 50 84 550 5.5
8-271-130 14 tonne M48 72 5 67 110 122 25 235 98 50 84 550 6.1
8-271-140 20 tonne M52 78 5 72 120 150 32 270 120 60 94 750 10.5
8-271-160 20 tonne M56 84 5.5 72 120 150 32 270 120 60 94 800 10.7
8-271-161 20 tonne M64 96 6 72 120 150 32 270 120 60 94 800 11.6
8-271-310 40 tonne M72 108 6 90 130 210 45 340 170 83 145 1200 30.6
8-271-350 40 tonnes M80 120 6 90 130 210 45 340 170 83 145 1500 31.6
8-271-400 40 tonnes M90 135 6 90 130 210 45 340 170 83 145 2000 33.9
Dimensional Drawing

Load Chart: 8-271 Lifting Point

Lifting Method 0 Degrees 2 at 0 degrees (via. lifting or spreader beam) 90 degrees 2 at 90 degrees (via. lifting or spreader beam) 2 at 0-45 or 45-60 degrees  2 with an unsymmetrical load 3 or 4 at 0-45 or 45-60 degrees 3 or 4 with an unsymmetrical load
Number of legs 1 2 1 2 2 2 2 3-4 3-4 3-4
Load direction 0° 0° 90° 90° 0-45° 45°-60° unsymm. 0-45° 45°-60° unsymm.
Product Code WLL (t)
8-271-004 0.9 1.8 0.6 1.2 0.84 0.6 0.6 1.26 0.90 0.6
8-271-006 1.2 2.4 0.7 1.4 0.98 0.7 0.7 1.47 1.05 0.7
8-271-013 2.6 5.2 1.5 3.0 2.10 1.5 1.5 3.15 2.25 1.5
8-271-020 4.0 8.0 2.5 5.0 3.50 2.5 2.5 5.25 3.75 2.5
8-271-035 7.0 14.0 4.0 8.0 5.60 4.0 4.0 8.40 6.00 4.0
8-271-060 10.0 20.0 6.0 12.0 8.40 6.0 6.0 12.60 9.00 6.0
8-271-080 15.0 30.0 10.0 20.0 14.00 10.0 10.0 21.00 15.00 10.0
8-271-120 17.0 34.0 13.0 26.0 18.20 13.0 13.0 27.30 19.50 13.0
8-271-130 18.0 36.0 14.0 28.0 19.60 14.0 14.0 29.40 21.00 14.0
8-271-140 25.0 50.0 20.0 40.0 28.00 20.0 20.0 42.00 30.00 20.0
8-271-160 28.0 56.0 20.0 40.0 28.00 20.0 20.0 42.00 30.00 20.0
8-271-161 28.0 56.0 20.0 40.0 28.00 20.0 20.0 42.00 30.00 20.0
8-271-310 50.0 100.0 40.0 80.0 56.00 40.0 40.0 84.00 60.00 40.0

Contact Us About This Product

If you wish to receive a quote for this product, please use the Pricing section to the right, this form is for general enquiries regarding this product only.

Regarding: Yoke 271 Metric Ball Bearing Swivel Lifting Point
Did you know?

You can also request a quote through the pricing tab!

You can easily add more than one item to the Quote Request. This is highly recommended as we will be able to suit your needs much more efficiently.

Share this page!

qrcode

Pricing

Sale Price £50.00

£45.00

Ex. VAT

Please Note: Buy online is only available to UK mainland customers and addresses. For anywhere else, please request a quote.

Availability

Usually 1-2 Days (Next working day delivery may be possible) - 1pm cut-off

Additional Information

Larger thread sizes may vary on availability. For urgent orders, please contact our sales team that will gladly assist.
