EcoWarrior WRTSB550 Counterbalanced Workshop Crane

EcoWarrior WRTSB550 Counterbalanced Workshop Crane

Manual Mobile Counterbalanced Workshop Crane with 5 Variable Capacity and Telescopic Jib Arm Settings. Maximum 550kg Lifting Capacity

Model:

WRTSB550

Quick Ref:

EWCM-5712

Crane Jib at Maximum Height and Maximum Reach

Crane Arm at Max Reach Position 5 - Front Side

Counterbalance Crane at Full Reach - Lowered

Counterbalanced Crane at Minimum Reach - Lowered

Front Side View In Position 1 With Hydraulic Ram Raised Halfway

Rear Side Of Counterweight Box and Transport Handle With Arm Raised

Rear Side of Counterweight Box and Transport Handle

Counterbalance Crane in Position 1 Lifting a Test Weight

WRTSB550 Crane in Position 1 Lifting a Test Weight

Manual Transport Movement Handle and Counterbalanced Weight Box

EcoWarrior Counterbalanced Manual Mobile Workshop Crane

The EcoWarrior Counterbalanced Manual Mobile Workshop Crane is designed for precise and controlled lifting in workshops, industrial environments and restricted working spaces. Its free-standing design and integrated counterbalance provide excellent manoeuvrability, making it suitable for handling loads where space is limited. With a five-position telescopic jib offering variable lifting capacities, this mobile workshop crane allows operators to select the appropriate configuration for each lifting task.

Featuring a heavy-duty swivel hook with a safety catch, a double-acting manual hydraulic pump and a pressure relief valve to help prevent overloading, the EcoWarrior crane combines practical operation with essential safety features. Its adjustable jib and compact design make it a versatile lifting solution for demanding workshop and maintenance applications.

Key Features of the EcoWarrior Mobile Workshop Crane

Counterbalanced Design: Free-standing construction with an integrated counterbalance for stable, versatile lifting.
Five Variable Capacity Settings: Adjustable lifting capacity to accommodate different loads and working positions.
Five-Position Telescopic Jib: Extends to suit different lifting requirements and improve access in restricted spaces.
Heavy-Duty Swivel Hook: Supplied with a safety catch for secure load attachment.
Double-Acting Manual Hydraulic Pump: Provides controlled hydraulic operation for efficient lifting and lowering.
Pressure Relief Valve: Helps prevent overloading during operation.
Compact, Manoeuvrable Design: Suitable for workshops and industrial environments where space is limited.
CE Marked: Supplied with CE marking.

EcoWarrior WRTSB550 Lifting Capacity Table

The EcoWarrior WRTSB550 Counterbalanced Crane features a five-position telescopic jib, allowing the lifting reach and capacity to be adjusted to suit the application. The rated lifting capacity decreases as the jib extends.

Jib Position / Reach	Rated Lifting Capacity
Minimum jib extension – Position 1	550kg
Jib Position 2	500kg
Jib Position 3	450kg
Jib Position 4	400kg
Maximum jib extension – Position 5	350kg
Full clear reach (1600mm) in front of wheels	150kg

Important: The crane's maximum rated capacity is 550kg at minimum jib extension. At full clear reach, the stated capacity is 150kg. Always refer to the manufacturer's capacity chart and operating instructions to confirm the permitted load at the required jib position and reach before lifting.

WRTSB550 Counterweight Crane Specifications

Specification	Measurement
Maximum capacity at minimum jib extension	550kg
Maximum clear reach in front of wheels	1,600mm
Maximum lift height	2,900mm
Overall dimensions (L × W × H)	2,100 × 1,050 × 1,760mm
Chassis dimensions (L × W × H, jib level)	1,650 × 910 × 1,730mm
Overall height when folded	870mm

A Versatile Counterbalanced Crane for Workshop Lifting

Whether used for machinery maintenance, component handling or general workshop lifting, the EcoWarrior Counterbalanced Mobile Workshop Crane offers adjustable reach and variable lifting capacities in one practical unit. Its telescopic jib, manual hydraulic operation and counterbalanced construction make it a versatile choice for lifting tasks where access, manoeuvrability and precise load positioning are important.
