Electric Work Positioner

Lightweight easily manoeuvrable electrically powered Lift work positioner with a 100kg or 150kg lifting capacity and up to 1700mm lift height.

Model:

EWP-657

Battery-Powered Electric Work Position Device

A range of extremely manoeuvrable, lightweight powered lifting units, designed to take the strain out of any lifting job from ground level to over shoulder height.

Ideal for use in narrow aisles and confined spaces. Perfect for all applications from pharmaceutical to catering, from packing line to food processing, from warehouse to office, kitchens, laboratories, retail outlets, etc.

Lifter Features

Lifting and lowering is controlled by a chain drive electrical motor.
Electronic regulation of lift/lowering, including soft start/stop, and electric overload protection.
Portable and adjustable hand control unit.
Maintenance-free / sealed battery.
Automatic battery charger.
Long handles for easy manoeuvring.
Supplied as standard with a platform.
Additional attachments available (see below).
Supplied with 4 non-marking swivel castor wheels (2 fitted with foot brakes).

As an alternative to this powered positioner, we also offer a similar manual work positioner unit that may also be of interest.

Dimensions and Specifications

Model	T24746	T24747
Capacity (kg)	100	150
Load Centre (mm)	235	235
Min. / Max. Lift Height (mm)	130 / 1700	130 / 1500
Platform Size: L x W (mm)	475 x 600	475 x 600
Fork Length (mm)	400	400
Width Over Forks (mm)	330	330
Battery (Ah/V)	12/24	12/24
Steer / Load Wheels Dia. (mm)	125 / 75	125 / 75
Dimensions: L x W x H (mm)	850 x 600 x 1970	825 x 600 x 1780
Weight (kg)	66	63

Optional Attachment for this Electric Work Positioner

Spindle / Boom

Diameter: 48mm
Length: 600mm

Double Spindle

Diameter: 47mm
Length: 450mm
Spindle Centre - Centre: 200mm

Roll Rotator

Roll Inner Diameter: 80-90mm
Roll Outer Diameter: 500mm
Roll Length: 250mm

V-Block / Cradle

Size: 400 x 400mm
Height: 80mm

200mm Raised Platform
