LIFTINGSAFETY

LiftingSafety Stainless Steel Atex Pallet Weighing Truck (ZONE 2, 22 and ZONE 1,22) Forks 550mm x 1182mm. From 500 to 2000kg. (4 Options)

Hazardous zone stainless steel pallet truck with weighing scales. Range From 500 to 2000kg.

Model:

SSAPT-3717


Description

+

Pallet truck scales, with built-in electronic weighing, suitable for harsh working conditions and dangerous areas classified as hazardous (ZONE 2, 22 and ZONE 1,22) in accordance with Ex II 3GD IIC T6 T130°C X protection. The weight detection made with four Atex certified IP68 stainless steel load cells guarantees the precision in all work conditions. Structure entirely in stainless steel. Available also CE-M APPROVED.

Main features

  • Maximum lifting capacity: 2000Kg.
  • Accuracy: +/- 0.1% of the maximum capacity.
  • Fork dimensions 1182 x 550 x 80 mm.
  • Weighs about 135 kg.
  • Bearing structure entirely in extra thick stainless steel.
  • Lifting pump in stainless steel.
  • Steering wheels with rubber coating.
  • Double loading rollers with a polyurethane coating.
  • Four IP68 stainless steel, Atex certified, shear-beam load cells.
  • Weight indicator with waterproof IP68 stainless steel case, easy to clean and resistant to harsh and corrosive environments; large high contrast 25mm LCD display, easily visible also in poor lighting conditions and waterproof membrane keypad, with 17 numerical / functional keys.
  • Calibration and Set-Up parameters configurable from keyboard or from PC.
  • Power supply through rechargeable battery, 40-hour approximate operating time.
  • Low battery warning. Programmable auto switch-off.
  • Equipped with 230Vac 50 Hz battery charger to be recharged in a safe area.

Selectable function

  • High Resolution Weighing x 10
  • Net/Gross or lb/kg conversion
  • Accumulation
  • Formula weighing
  • +/- Check weighing
  • Percentage weighing
  • Counting(Max. resolution of 1.500.000 divisions)
  • In/Out Truck weighing
  • Hold and Peak
  • Peer-to-peer(up to 4 remote connectible indicators)
  • Set Point Control (with optional interface)

Keyboard function

  • Zeroing, Automatic tare, Presetable tare, Print and/or data transmission command, Function command.

Option only available at time of order

  • Parking brake system with command pedal.
  • 680 mm fork width (ask for price estimate).
  • Special fork length from 850 to 1500 mm (ask for price estimate).
  • 3000 kg capacity (ask for price estimate).
  • High resolution version (ask for estimate).
  • Special wheels available with price estimate.

Version available

Code Max capacity (kg) Division (kg) CE-M division (kg)
3717-T8144 500 / 1000 / 2000 0,2 / 0,5 / 1 -
3717-T8145 1000 / 2000 - 0,5 / 1
3717-T8146 500 / 1000 / 2000 0,2 / 0,5 / 1 -
3717-T8147 1000 / 2000  - 0,5 / 1
Pricing

+
Part N° Max capacity (kg) Division (kg) CE-M division (kg) Guide Price Quantity
3717-T8144 500 / 1000 / 2000 0,2 / 0,5 / 1 - £  4230.00
3717-T8145 1000 / 2000 - 0,5 / 1 £  4510.00
3717-T8146 500 / 1000 / 2000 0,2 / 0,5 / 1 - £  5640.00
3717-T8147 1000 / 2000 - 0,5 / 1 £  5920.00
Add to Quote Basket   ?

Pallet truck scales, with built-in electronic weighing, suitable for harsh working conditions and dangerous areas classified as hazardous (ZONE 2, 22 and ZONE 1,22) in accordance with Ex II 3GD IIC T6 T130°C X protection. The weight detection made with four Atex certified IP68 stainless steel load cells guarantees the precision in all work conditions. Structure entirely in stainless steel. Available also CE-M APPROVED.

Main features

  • Maximum lifting capacity: 2000Kg.
  • Accuracy: +/- 0.1% of the maximum capacity.
  • Fork dimensions 1182 x 550 x 80 mm.
  • Weighs about 135 kg.
  • Bearing structure entirely in extra thick stainless steel.
  • Lifting pump in stainless steel.
  • Steering wheels with rubber coating.
  • Double loading rollers with a polyurethane coating.
  • Four IP68 stainless steel, Atex certified, shear-beam load cells.
  • Weight indicator with waterproof IP68 stainless steel case, easy to clean and resistant to harsh and corrosive environments; large high contrast 25mm LCD display, easily visible also in poor lighting conditions and waterproof membrane keypad, with 17 numerical / functional keys.
  • Calibration and Set-Up parameters configurable from keyboard or from PC.
  • Power supply through rechargeable battery, 40-hour approximate operating time.
  • Low battery warning. Programmable auto switch-off.
  • Equipped with 230Vac 50 Hz battery charger to be recharged in a safe area.

Selectable function

  • High Resolution Weighing x 10
  • Net/Gross or lb/kg conversion
  • Accumulation
  • Formula weighing
  • +/- Check weighing
  • Percentage weighing
  • Counting(Max. resolution of 1.500.000 divisions)
  • In/Out Truck weighing
  • Hold and Peak
  • Peer-to-peer(up to 4 remote connectible indicators)
  • Set Point Control (with optional interface)

Keyboard function

  • Zeroing, Automatic tare, Presetable tare, Print and/or data transmission command, Function command.

Option only available at time of order

  • Parking brake system with command pedal.
  • 680 mm fork width (ask for price estimate).
  • Special fork length from 850 to 1500 mm (ask for price estimate).
  • 3000 kg capacity (ask for price estimate).
  • High resolution version (ask for estimate).
  • Special wheels available with price estimate.

Version available

Code Max capacity (kg) Division (kg) CE-M division (kg)
3717-T8144 500 / 1000 / 2000 0,2 / 0,5 / 1 -
3717-T8145 1000 / 2000 - 0,5 / 1
3717-T8146 500 / 1000 / 2000 0,2 / 0,5 / 1 -
3717-T8147 1000 / 2000  - 0,5 / 1
Part N° Max capacity (kg) Division (kg) CE-M division (kg) Guide Price Quantity
3717-T8144 500 / 1000 / 2000 0,2 / 0,5 / 1 - £  4230.00
3717-T8145 1000 / 2000 - 0,5 / 1 £  4510.00
3717-T8146 500 / 1000 / 2000 0,2 / 0,5 / 1 - £  5640.00
3717-T8147 1000 / 2000 - 0,5 / 1 £  5920.00
Add to Quote Basket   ?
