Easy Slope Mobile Steps with 48° / 54° Incline, Strong Reinforced Handrails and Work Platform

Easy Slope Mobile Steps.

Model:

ESMS-1372


Description

+
  • Easy Slope 48 degree or Standard Slope 54 degree incline
  • Strong reinforced handrails
  • Extra wide treads:- Easy Slope: 750mm wide x 180mm deep, Standard Slope: 750mm wide x 160mm deep
  • Platform size: 800mm wide x 500mm deep

Available in two versions, the easy slope 48 degree angle and the standard slope 54 degree angle. The 48 degree safety angle enables the user to turn around and descend the steps facing forward with safety and comfort. The standard 54 degree angle is ideal for use in areas where space is limited. Welded platform rails and handrails, with expanded steel mesh treads and platforms. Fitted with lever operated retractable front castors and a safety bar which deters access to steps when in the mobile position.

  • Finish: Epoxy Powder Coated - Grey
  • 6 step units and above are sent folded for delivery - easy to erect
  • Platform Handrail Height: 1000mm
  • Wheels: 2 x 200mm Black Rubber Tyred 2 x 100mm Nylon Castors
Pricing

+
Part N° Slope Angle Of Steps Platform Height (mm) Number of Steps Overall Dimensions When In Use (H x W x D mm) Total Weight (kg) Guide Price Quantity
1372-T6045 48° 690 3 1690 x 1000 x 1125 42 Quote Required
1372-T6046 48° 920 4 1920 x 960 x 1310 50 Quote Required
1372-T6047 48° 1150 5 2150 x 960 x 1515 69 Quote Required
1372-T6048 48° 1380 6 2380 x 980 x 1725 82 Quote Required
1372-T6049 48° 1610 7 2610 x 1030 x 1930 96 Quote Required
1372-T6050 48° 1840 8 2840 x 1080 x 2140 112 Quote Required
1372-T6051 48° 2070 9 3070 x 1130 x 2345 123 Quote Required
1372-T6052 48° 2300 10 3300 x 1180 x 2555 136 Quote Required
1372-T6053 48° 2530 11 3530 x 1230 x 2760 146 Quote Required
1372-T6054 48° 2760 12 3760 x 1280 x 2965 175 Quote Required
1372-T6055 54° 690 3 1690 x 1000 x 1095 42 Quote Required
1372-T6056 54° 920 4 1920 x 960 x 1260 50 Quote Required
1372-T6057 54° 1150 5 2150 x 960 x 1430 69 Quote Required
1372-T6058 54° 1380 6 2380 x 980 x 1595 82 Quote Required
1372-T6059 54° 1610 7 2610 x 1030 x 1765 96 Quote Required
1372-T6060 54° 1840 8 2840 x 1080 x 1930 112 Quote Required
1372-T6061 54° 2070 9 3070 x 1130 x 2095 123 Quote Required
1372-T6062 54° 2300 10 3300 x 1180 x 2265 136 Quote Required
1372-T6063 54° 2530 11 3530 x 1230 x 2430 146 Quote Required
1372-T6064 54° 2760 12 3760 x 1280 x 2600 175 Quote Required
Pricing Currency: Not available at the moment. Add To Quote Request   ?
