Trolley Universal 'End Stop' with Rubber Buffers, to suit Flange Width up to 300mm

Beam Buffer End Stops. Quick and Easy to Assemble and Install, for Devices with up to 10 tonne Lifting Capacity.

Model:

BBES-4872


With so many different hoists and trolleys on the market this can sometimes lead to problems when fitting end stops on cranes, monorails, monorail systems, slewing jibs, etc.

Attaching stop plates or stop angles by screwing or welding is time consuming and potentially expensive. These quick and easy to install buffers offer both technical and economic advantages.

The un-tightened trolley buffer on the support flange can be easily moved and positioned and then secured without the need for drilling and welding.

The standard manufactured unit sizes are suitable for parallel IPE beams with flange widths from 46 to 300mm and flange thicknesses from 7mm to 25mm.

Universal Track End Stop

Universal Flange Fitted End Stop 46 to 82mm

  • Manual and electric trolleys up to 1000kg Capacity
  • Corrosion resistant
  • Parallel flange profile beams
  • Flange thickness to 15mm
  • Beam width 46 to 82mm
  • Weight: 2kg
Adjustable Universal End Stop With Buffers

Universal Flange Fitted End Stop 82 to 300mm

  • Manual and electric trolleys up to 10,000kg Capacity
  • Corrosion resistant
  • Parallel flange profile beams
  • Flange thickness to 7 to 25mm
  • Beam width 82 to 300mm
  • Weight: 2.5kg

Specifications

Model Type Adjustment Range (mm) Carrying Capacity (t) Max. Permitted Hoisting Device Weight (kg) Max. Permitted Operating Speed (m/min)

46-82 1.0 Max. 120 16

82-300 0.15 – 1.6 160 25
82-300 2.0 250 20
82-300 2.5 250 20
82-300 3.2 250 20
82-300 4.0 250 20
82-300 5.0 400 20
82-300 6.3 400 20
82-300 8.0 900 16
82-300 10.0 900 16

Fitting

Flange Fitted End Stop Clamp

46mm to 82mm End Stop

Flange Fitted End Stop With Rubber Stops

82mm to 300mm End Stop

With so many different hoists and trolleys on the market this can sometimes lead to problems when fitting end stops on cranes, monorails, monorail systems, slewing jibs, etc.

Attaching stop plates or stop angles by screwing or welding is time consuming and potentially expensive. These quick and easy to install buffers offer both technical and economic advantages.

The un-tightened trolley buffer on the support flange can be easily moved and positioned and then secured without the need for drilling and welding.

The standard manufactured unit sizes are suitable for parallel IPE beams with flange widths from 46 to 300mm and flange thicknesses from 7mm to 25mm.

Universal Track End Stop

Universal Flange Fitted End Stop 46 to 82mm

  • Manual and electric trolleys up to 1000kg Capacity
  • Corrosion resistant
  • Parallel flange profile beams
  • Flange thickness to 15mm
  • Beam width 46 to 82mm
  • Weight: 2kg
Adjustable Universal End Stop With Buffers

Universal Flange Fitted End Stop 82 to 300mm

  • Manual and electric trolleys up to 10,000kg Capacity
  • Corrosion resistant
  • Parallel flange profile beams
  • Flange thickness to 7 to 25mm
  • Beam width 82 to 300mm
  • Weight: 2.5kg

Specifications

Model Type Adjustment Range (mm) Carrying Capacity (t) Max. Permitted Hoisting Device Weight (kg) Max. Permitted Operating Speed (m/min)

46-82 1.0 Max. 120 16

82-300 0.15 – 1.6 160 25
82-300 2.0 250 20
82-300 2.5 250 20
82-300 3.2 250 20
82-300 4.0 250 20
82-300 5.0 400 20
82-300 6.3 400 20
82-300 8.0 900 16
82-300 10.0 900 16

Fitting

Flange Fitted End Stop Clamp

46mm to 82mm End Stop

Flange Fitted End Stop With Rubber Stops

82mm to 300mm End Stop
