Crosby A378 Sorting Hooks

Sorting Hook with Handle: A-378N Series

All of the Crosby A378 Sorting Hooks for hoisting are Forged Alloy Steel, and as standard, they are all quenched and tempered; the deep straight throat permits efficient handling of flat plates or large cylindrical shapes.

Design factor: 4:1

Metric Dimensions & Specifications

Working Load Limit at tip of Hook (t)*	Working Load Limit at bottom of Hook (t)*	A-378 Stock No.	Style	Weight Each (lkg)	Dimensions (mm)
					I.D. of Eye	Overall Length	Opening at top of Hook	Radius at bottom of Hook
2	7.5	1028033	With Handle	2.91	35.0	246	71.4	15.9

Imperial Dimensions & Specifications

Working Load Limit at tip of Hook (t)*	Working Load Limit at bottom of Hook (t)*	A-378 Stock No.	Style	Weight Each (lbs.)	Dimensions (in.)
					I.D. of Eye	Overall Length	Opening at top of Hook	Radius at bottom of Hook
2	7.5	1028033	With Handle	6.42	1.38	9.69	2.81	.625

Crosby-catalogue-page-number-122-123.pdf

Product Warnings

PDF containing all warning information relevant to the safe use of this product

(approx. 0.3Mb)

crosby-catalogue-page-114.pdf

(approx. 0.2Mb)

Contact Us About This Product

If you wish to receive a quote for this product, please use the tab, this form is for general enquiries regarding this product only.

Regarding: Crosby A378 Sorting Hooks

Full Name: *

Email Address: *

Telephone:

Country:

Subject: *

Message: *

Attachment: - Optional
(jpg,gif,png,webp,pdf,doc,xls)

I agree to the Terms & Conditions and the Terms & Conditions of Export (if applicable). I agree to having my data stored in accordance with the Privacy Policy. I want to get exclusive email offers.

Did you know?

You can also request a quote through the pricing tab!

You can easily add more than one item to the Quote Request. This is highly recommended as we will be able to suit your needs much more efficiently.

Share this page!

Part N°	Working Load Limit at tip of Hook (t)*	Working Load Limit at bottom of Hook (t)*	Type	Weight (kg)	Unit Price
2412-T15612 1028024	1.8	6.8	Without Handle	2.91	Quote Required
2412-T15613 1028033	1.8	6.8	With Handle	2.91	Quote Required

Please Note: Buy online is only available to UK mainland customers and addresses. For anywhere else, please request a quote.

Sorting Hook with Handle: A-378N Series

Design factor: 4:1

Metric Dimensions & Specifications

Working Load Limit at tip of Hook (t)*	Working Load Limit at bottom of Hook (t)*	A-378 Stock No.	Style	Weight Each (lkg)	Dimensions (mm)
					I.D. of Eye	Overall Length	Opening at top of Hook	Radius at bottom of Hook
2	7.5	1028033	With Handle	2.91	35.0	246	71.4	15.9

Imperial Dimensions & Specifications

Working Load Limit at tip of Hook (t)*	Working Load Limit at bottom of Hook (t)*	A-378 Stock No.	Style	Weight Each (lbs.)	Dimensions (in.)
					I.D. of Eye	Overall Length	Opening at top of Hook	Radius at bottom of Hook
2	7.5	1028033	With Handle	6.42	1.38	9.69	2.81	.625
