The Crosby Straightpoint LoadSafe Compression Load Cell. No longer hindered by troublesome and hard to maintain cables, large-scale projects can now be completed in a fraction of the time previously required.
Multiple compression load cells can all connect wirelessly to INSIGHT via a USB dongle, their iOS or Android app (If Bluetooth), or their SW-HHP wireless handheld display.
Maintenance and repair costs are all but eliminated due to the absence of cables and connectors. The flexibility of the product opens the door to a large number of applications in the heavy lift, energy, defense, rigging, shipping, and general transportation sectors.
Crosby Straightpoint’s LoadSafe is machined from high grade 17-4PH stainless steel, providing excellent strength and corrosion resistance, which makes them suitable for the most arduous industrial conditions.
Connected to Crosby Straightpoint’s INSIGHT, the WNI load cell can be used to weigh and verify center of gravity of large and heavy objects, which may not be evenly proportioned. The system will report weight on each individual load cell, total weight and C-of-G in an html report based on ISO19901
Features
- Industry leading wireless range up to 1000m or 3,280ft.
- High grade 17-4PH stainless steel, providing excellent strength and corrosion resistance.
- Frequency: Proprietary 2.4 GHz wireless.
- Accuracy of ±0.1% FS.
- Environmentally sealed to IP67 or NEMA6.
- Stocked capacities up to 1000t.
- Internal antenna.
- ATEX & IECEx version for hazardous area zones 0, 1 & 2 available.
- Battery life of 1200 hrs.
- Compact size.
- Remote on/off from handheld display or software.
- Design validated by FEA.
- Bluetooth option is available and is supplied with a free HHP App for iOS and Android.
- Handheld available, but not included.
- Design Factor: 3:1
- Battery Type: Handheld 2 x AA / Loadcell 4 x AA.
- Operating Temperature: -10°C to +50°C.
- Accuracy: ±0.1% of full scale.
- Battery Life: Handheld - 40 hours / Loadcell 1,200 hours continuous (Loadcell 500 hours if Bluetooth).
- System Range (max): 1,000 m (100 m if Bluetooth), (500 m if ATEX/IECEx).
- Data Rate: 3 Hz (configurable to 200Hz)
Dimensions & Specifications
| Stock No. |
Model |
Capacity (t) |
Resolution (t) |
Weight (kg) |
Dimensions (mm) |
| ØA |
B |
ØD |
E |
F |
G |
H |
I |
| 2789197 |
WNI5TC |
5 |
0.001 |
6.2 |
100 |
127 |
59 |
16 |
M18 x 2.5 |
152 |
158 |
22 |
| 2789191 |
WNI10TC |
10 |
0.002 |
6.2 |
100 |
127 |
59 |
16 |
M18 x 2.5 |
152 |
158 |
22 |
| 2789193 |
WNI25TC |
25 |
0.005 |
6.2 |
100 |
127 |
59 |
16 |
M18 x 2.5 |
152 |
158 |
22 |
| 2789196 |
WNI50TC |
50 |
0.01 |
6.2 |
100 |
127 |
59 |
16 |
M20 x 2.5 |
152 |
158 |
22 |
| 2789190 |
WNI100TC |
100 |
0.05 |
15.5 |
152 |
184 |
80 |
26 |
M20 x 2.5 |
432 |
208 |
33 |
| 2789192 |
WNI150TC |
150 |
0.05 |
15.5 |
152 |
184 |
80 |
26 |
M20 x 2.5 |
432 |
208 |
33 |
| 2789194 |
WNI300TC |
300 |
0.1 |
65 |
185 |
300 |
155 |
28 |
M20 x 2.5 |
432 |
241 |
49 |
| 2789195 |
WNI500TC |
500 |
0.2 |
65 |
185 |
300 |
155 |
28 |
M20 x 2.5 |
432 |
241 |
49 |
| 2789138 |
WNI1000TC |
1,000 |
0.5 |
172 |
362 |
310 |
270 |
40 |
M30 x 3.5 |
950 |
422 |
102 |
