Ingersoll Rand "C400" Lightweight Aluminium Ratchet Puller Hoist for Lifting and pulling Applications - 770kg or 1800kg (Lifting Capacity)

Model:  IR-3408

Height of Lift

Unit Price £ Quote Only
Part N°: 3408-3934868   Add to Quote Request

C Series Lightweight aluminium design, reversible handle for easy position changes.

C Series Ratchet Hoist

The C-Series includes rugged cast aluminum wire rope pullers designed to store more wire rope than all-steel ratchet pullers. Rigged double line, they handle those long reach pulling or lifting jobs up to 3,400 lbs, with no problem.

"One notch at a time" lowering is assured by the ratchet and pawl system. The gear teeth are IR's "Buttress Tooth" design for additional strength and longer gear life.

Cable Puller Features

  • 4:1 design factor lifting, lowering and pulling. Meets ASME B30.21 Specifications.
  • Overload safety handle designed to noticeably bend.
  • Lightweight aluminum frame.
  • Alloy steel load hook with safety latches.
  • One piece cast aluminum drum.
  • Buttress tooth design improves load gear life.
  • Solid steel drive and holding dog, not laminated plates.
  • Galvanized aircraft quality wire rope.
  • Ratchet and pawl system provides safe, one notch at a time lowering.
  • Cable guide and shield protects wire rope and spools cable evenly on drum.
  • Reversible handle changes position easily, so pull is always possible in the right direction against the load.
  • Easy to repair, replacement parts available.
  • Plated external parts for corrosion resistance.

Strap Puller Features

  • An extension of our premium C Series, the C Series strap pullers offer the following unique features:
  • Three hooks allow 2 ton capacity; 6 foot pull with double line and 1 ton capacity with 12 foot pull using single line.
  • Non-conductive, corrosion resistant, high strength synthetic strap will not kink or bind.
  • Easy pay out of strap for fast set-up.


Model Nominal load capacity (kg) Pull to lift rated load (kg) Number of falls Pulling distance (m) Cable diameter (mm) Net weight (kg) Dimensions (mm)
Dimensional Drawing A B C D
C400H 770 / 1540 26 /28 1 or 2 6.0 / 3.0 6.3 7.3 Dimensions 432 / 559 127 178 22
C400S 900 / 1800 29 / 31 1 or 2 3.6 / 1.8 - 7.3 432 / 559 127 178 22
