Quick Ref: MMST-658
Showing 4 of 7

Mini Manual Stacker Truck - 400kg Lifting Capacities. 1200mm, 1500mm or 1700mm Lift Height.

Model:  MMST-658

Mini Stacker Boom Adjustable Hook Platform Reel Rotator
Part N° Lift Height (mm) Net Weight (kg) Overall Size (H x W x L) Guide Price Quantity
658-T14195 1200 84 1440 x 600 x 1040 £  868.50
658-T14196 1500 90 1740 x 600 x 1040 £  913.50
658-T14197 1700 95 1940 x 600 x 1040 £  958.50
658-T14198 OPTIONAL EXTRAS N/A N/A Quote Required
658-T14199 Adjustable Hook N/A N/A £  180.00
658-T14200 Platform N/A N/A £  42.00
658-T14201 Reel Rotator N/A N/A £  375.00
658-T14202 Boom N/A N/A £  195.00
Pricing Currency: Add To Quote Request   ?

Mini Manual Stacker Truck - 1200mm to 1700mm Lift Heights.

400kg Capacity, 1.2, 1.5 and 1.7m Lift Heights.

Features

  • This Product Features Unique Perspex Chain Protection
  • Ideal for Lifting and Transporting Work Pieces and also Working in a Limited Space.
  • Capable of Operating in Lorry or Container.
  • Highly Manoeuvrable and Low Maintenance Cost
  • Foot Pump Hydraulic Lifting System
  • Twin Total Stop Top Quality Non-Marking Poly Wheels with Foot Brakes.
  • Easy To Fit with Optional Multi Purpose Attachments.
  • Tough Powder Coated Finish.
  • Hard Chromium Plated Frame Tube.

Specifications

  • Adjustable Forks (mm): 110 (W) x 650 (L)
  • Lowered 85mm
  • Fork Length 650mm
  • Fork Width - Adjustable 235 - 560mm
  • Lift Per Stroke 25mm
  • Load Centre 300mm
  • PU Wheel Dia 75 x 150mm

Manual Mini Stacker Optional Attachments

sms mini stacker boom mini stacker mms  optional stacker platform wjmms Stacker_reel_rotator_wjmms
