Counterweight Fork Truck - Pallet Truck (Manual And Powered Options)

Counterbalance Workshop Fork Lift Truck

This is a variation on our counter balanced floor / workshop crane fitted with fork lift truck tynes/tines instead of a crane jib arm. The counterbalanced weight at the rear of the chassis means that there is no need for front facing stabilizing feet as used on a stacker truck. This means that the counterbalanced workshop fork lift is far more versatile than a stacker.

We manufacture capacities up to 2000kg and lift heights to suit the customers requirements. Most of the features available on a standard floor crane can be adapted to the counterbalanced fork truck, all the fork lifts are made her in the UK so please contact our sales department with you requirements and we will be more than happy to provide you with a competitive quotation. Please phone our sales team on 01977 684600 if you require any assistance or further information.

Note: The pictures shown are our artists impression only and are only indicative of our capability. (for display purposes only) All cranes are made individually and the the design may be subject to change according to your required specification; the pictures are not to scale, general arrangement drawings will be issued for approval on receipt of your order.

Forklift Floor Crane Features

• Allows user freedom to work very close to machines or over obstructions
• Meets all safety standards and is supplied fully CE certified.
• Unique product fully customized.
• All Welded construction, a quality manufactured piece of lifting equipment
• All models manual lift models feature a heavy duty, double-acting pump for fast action, also supplied with electric lift and travel.
• Fitted with a op quality British manufactured hydraulics
• Fitted with hard wearing polyurethane front wheels and swivel Castor's on the rear for easy movement of the crane when operational
• wheels / Castor's to customers specification
• Heavy duty construction
• Each crane has been individually tested to 25% overload as a complete unit
• Sand or concrete blocks can be used on 152kg, 254kg and 508kg, Models 750kg and 1000kg, 1500kg and 2000kg require Metal Ballast
• Stainless steel fork trucks lift work shop trucks also available
• Come with a 12 month guarantee.

Views of Features

Optional Features and Accessories

Listed below are some additional features that can be added to any of our Vertical Lift counterbalance floors cranes to customise the cranes, making it better suited to your working environment. All these features can also be supplied with our stainless steel cranes.

Out-riggers	Fork lift truck lifting pockets	Directional locking castors or anti static castors
Detachable and Adjustable Fork Tines	Lifting and slinging point for overhead crane	Power Travel
Paint finish suitable for offshore use or powder coated	Stainless Steel Forked Floor Crane

Crane Material Mild Steel Stainless Steel

Safe Working Load 152kg 254kg 508kg 750kg 1000kg 1500kg 2000kg

Height of Lift (mm)

Fork Length (mm)

Overall Maximum Width of Forks

Method of Lifting Manual Hand Winch Manual Hydraulic System Electric Lift - 12v Hydraulics

Further Options

 Outriggers
 Forklift Truck Lifting Pockets
 Directional Locking Castors
 Anti-static Castors
 Lifting and Slinging Points
 Painted for Offshore Use
 Powder Coated
 Power Travel
 Anti-sparking Features

Additional Information

Quantity

Guide Price (each) : Quote Required
NOTE: This item has separate transport costs (£ 60.00)

Part N°: 2938-1715156
