Quick Ref: TLEL-3742
Showing 2 of 3

Ridgegear "RGL9" Twin Leg Elasticated Webbing Fall Arrest Lanyard, 100% Tie Off. Choice of Karabiner, Scaffold Hook or Snap Hook - Length Options 1.3m or 1.8 Metre

Model:  RGL9 / TLEL-3742

Steel Screwgate
Aluminium Double Action Snap Hook
Steel Twist Lock Karabiner
Steel Double Action Snap Hook.
Steel Screw Gate Karabiner Aluminium Double Action Snap Hook Steel Twist Lock Karabiner Steel Double Action Snap Hook
Part N° Length (m) End Fittings Unit Price Quantity
3742-T8202
RGL9/1.3
1.3 None £  49.31
3742-T8203
RGL9/1.8
1.8 None £  50.49
3742-T8232
RGL9/1.3 + 2 x RGK11
1.3 2 x Double action scaffold snap karabiner - aluminium and 11mm Screwgate delta link - steel £  95.09
3742-T8233
RGL9/1.8 + 2 x RGK11
1.8 2 x Double action scaffold snap karabiner - aluminium and 11mm Screwgate delta link - steel £  96.27
3742-T8245
RGL9/1.3 + 2 x RGK1
1.3 2 x Steel Screw Gate Karabiner £  58.33
3742-T8246
RGL9/1.8 + 2 x RGK1
1.8 2 x Steel Screw Gate Karabiner £  59.51
3742-T8247
RGL9/1.3 + 2 x RGK3
1.3 2 x Steel Twist Lock Karabiner £  98.38
3742-T8248
RGL9/1.8 + 2 x RGK3
1.8 2 x Steel Twist Lock Karabiner £  99.56
3742-T8275
RGL9/1.3 + 2 x RGK10
1.3 2x Steel Double Action Snap Hook £  66.42
3742-T8276
RGL9/1.8 + 2 x RGK10
1.8 2x Steel Double Action Snap Hook £  67.60
Add to Quote Basket   ?

Twin leg elasticated lanyard allows leg movement between anchorage points by means of double clipping.

Twin Leg Elasticated Lanyard

The RGL9 has a similar specification to the RGL6, and is supplied in two lengths measured at full expansion: 1.3m and 1.8m.

The RGL9 is a twin leg lanyard, the extra leg allows movement between anchorage points by means of double clipping. This system is generally used for tower climbing, steel erecting, scaffolding and maintenance on open structures. When used in conjunction with two girder slings (RGK26), the RGL9 can be used as a means of progression through suitable structures where no fixed lifeline or eye bolts are available. The elastication in the lanyard reduces the amount of hanging slack in the lanyard, which can be helpful when working in tight spaces to help reduce trip hazards and entanglement.

This lanyard can be fitted with a variety of different karabiners.

Specification

  • Accredited to: EN354 and EN355
  • Web material: 35mm tubular webbing and tear webbing and >25kn backing webbing.
  • Fittings: 2 x RGK11 Scaffold hooks and RGK12 delta link
  • Weight: 0.5kg
  • Max arrest force: <6kN



Can be fitted with the three following connectors

  • Steel Screw Gate
  • Steel nTwist Lock Karabiner
  • Aluminium Double Action Snap Hook
rgl9-specification.pdf

RGL9 Specifications

(approx. 0.4Mb)
