Carriage Mounted High Lift Fork Jib. Arm Telescopic By Hydraulic Ram - Range From 210kg to 4000kg
Model: HLTJ-615High Lift Telescopic Jib.
- All the features of the standard model but with the benefit of extra lif
t capability. - Quick release button hangers also available.
- Jibs for bar-mounted and DIN spec. carriage also available.
Specifications
| Model | Truck Capacity at 500mm (kg) |
Load Centre Capacity at 500mm (kg) | Load Centre Capacity at 750mm (kg) | Load Centre Capacity at 1000mm (kg) | Load Centre Capacity at 1250mm (kg) | Load Centre Capacity at 1500mm (kg) | Load Centre Capacity at 1750mm (kg) | Load Centre Capacity at 2000mm (kg) | Load Centre Capacity at 2250mm (kg) | Load Centre Capacity at 2500mm (kg) | Load Centre Capacity at 2750mm (kg) | Load Centre Capacity at 3000mm (kg) |
| 615-12358 | 2000 | 1800 | 1400 | 1100 | 900 | 720 | 580 | 500 | 360 | 330 | 260 | 210 |
| 615-12359 | 2500 | 2200 | 1800 | 1400 | 1100 | 1000 | 850 | 750 | 560 | 440 | 320 | 230 |
| 615-12360 | 3000 | 2700 | 2050 | 1450 | 1200 | 1100 | 900 | 840 | 670 | 490 | 360 | 270 |
| 615-12361 | 3500 | 3100 | 2500 | 1900 | 1500 | 1200 | 1000 | 900 | 730 | 580 | 450 | 370 |
| 615-12362 | 4000 | 3500 | 2700 | 2000 | 1600 | 1300 | 1100 | 1000 | 820 | 670 | 540 | 460 |
NOTE: Pricing and specifications may be subject to change without notice. Prices shown may be UK only prices and therefore export pricing may vary dependant on location.
Images are for display purposes only.
