Electric Powered Lift Work Positioners - Capacities up to 150kg, & up to 1700mm Lift Height

Lightweight Easily Manoeuvrable Electric Powered Lifting Devices.

Model:

EWP-657


A range of extremely manoeuvrable, lightweight powered lifting units, designed to take the strain out of any lifting job from ground level to over shoulder height.

Ideal for use in narrow aisles and confined spaces. Perfect for all applications from pharmaceutical to catering, from packing line to food processing, from warehouse to office, kitchens, laboratories, retail outlets, etc.

Features

  • Lifting / Lowering by chain drive electrical motor.
  • Electronic regulation of lift / lowering including soft start/stop, electric overload protection.
  • Portable and adjustable hand control unit.
  • Maintenance free / sealed battery.
  • Automatic battery charger.
  • Long handles for easy maneuvering.
  • Supplied as standard with platform.
  • Additional attachments available (see below).
  • Supplied with 4 non marking swivel castor wheels, (2 fitted with foot brakes).

Dimensions and Specifications

Model E100 E150
Capacity (kg) 100 150
Load Centre (mm) 235 235
Min. / Max. Lift Height (mm) 130 / 1700 130 / 1500
Platform Size: L x W (mm) 475 x 600 475 x 600
Fork Length (mm) 400 400
Width Over Forks (mm) 330 330
Battery (Ah/V) 12/24 12/24
Steer / Load Wheels Dia. (mm) 125 / 75 125 / 75
Dimensions: L x W x H (mm) 850 x 600 x 1970 825 x 600 x 1780
Weight (kg) 66 63

Optional Attachments

Spindle / Boom

Boom Attachment

Diameter: 48mm

Length: 600mm

Double Spindle

Double Spindle Attachment

Diameter: 47mm

Length: 450mm

Spindle Centre - Centre: 200mm

Roll Rotator

Roll Rotator

Roll Inner Diameter: 80-90mm

Roll Outer Diameter: 500mm

Roll Length: 250mm

V-Block / Cradle

V Block Cradle

Size: 400 x 400mm

Height: 80mm

200mm Raised Platform

Electric Lift Raised Platform
Options
Part N° Capacity (kg) Load Centre (mm) Min. / Max. Lift Height (mm) Weight (kg) Guide Price Quantity
657-T24746 100 235 130 / 1700 66 £  1718.68
657-T24747 150 235 130 / 1500 63 £  1856.18
Add to Quote Basket   ?

A range of extremely manoeuvrable, lightweight powered lifting units, designed to take the strain out of any lifting job from ground level to over shoulder height.

Ideal for use in narrow aisles and confined spaces. Perfect for all applications from pharmaceutical to catering, from packing line to food processing, from warehouse to office, kitchens, laboratories, retail outlets, etc.

Features

  • Lifting / Lowering by chain drive electrical motor.
  • Electronic regulation of lift / lowering including soft start/stop, electric overload protection.
  • Portable and adjustable hand control unit.
  • Maintenance free / sealed battery.
  • Automatic battery charger.
  • Long handles for easy maneuvering.
  • Supplied as standard with platform.
  • Additional attachments available (see below).
  • Supplied with 4 non marking swivel castor wheels, (2 fitted with foot brakes).

Dimensions and Specifications

Model E100 E150
Capacity (kg) 100 150
Load Centre (mm) 235 235
Min. / Max. Lift Height (mm) 130 / 1700 130 / 1500
Platform Size: L x W (mm) 475 x 600 475 x 600
Fork Length (mm) 400 400
Width Over Forks (mm) 330 330
Battery (Ah/V) 12/24 12/24
Steer / Load Wheels Dia. (mm) 125 / 75 125 / 75
Dimensions: L x W x H (mm) 850 x 600 x 1970 825 x 600 x 1780
Weight (kg) 66 63

Optional Attachments

Spindle / Boom

Boom Attachment

Diameter: 48mm

Length: 600mm

Double Spindle

Double Spindle Attachment

Diameter: 47mm

Length: 450mm

Spindle Centre - Centre: 200mm

Roll Rotator

Roll Rotator

Roll Inner Diameter: 80-90mm

Roll Outer Diameter: 500mm

Roll Length: 250mm

V-Block / Cradle

V Block Cradle

Size: 400 x 400mm

Height: 80mm

200mm Raised Platform

Electric Lift Raised Platform
Options
Part N° Capacity (kg) Load Centre (mm) Min. / Max. Lift Height (mm) Weight (kg) Guide Price Quantity
657-T24746 100 235 130 / 1700 66 £  1718.68
657-T24747 150 235 130 / 1500 63 £  1856.18
Add to Quote Basket   ?
