Budget Aluminium Lifting Tripod - 500kg SWL
Model: ALT-1386
Lightweight and Adjustable Aluminium Lifting Tripod at capacity.
The ALT-1386 Lifting Tripod has now been superseded by a newer model, the AMT-2792 Man-riding and Rescue Tripod
Optional Extras
Hand winch at 180kg SWL, with quick attach aluminium bracket and a choice of rope capacities including: 20, 25, 35 and 50 metres
Heavy Duty storage bag for Tripod kit
Features
- Aluminium construction for ease of lifting
- Adjustable from 134cm fully retracted to 214cm fully extended
- Telescopic legs
- Secondary safety anchorage
- Supplier with security chain around the base
- Stabilising feet with rubber grips
Technical Information
- Working Load Limit: 500kg
- Breaking force: 22kN
- Version with webbing or chain
- Weight:
- - 13.60kg - with webbing
- - 16.60kg - with chain
- We deliver tripod with chain and webbing.
- Head - Made of hi strength cast aluminium
- Eyebolt - One central and one back.
Hand Winch (Option A)
- Automatic brake
- Cable: 20m
- Weight: 13kg
- Working load: 180kg
- Breaking force: 1800kg
Hand Winch Dimensions
(approx. 0.1Mb)
Hand Winch With Tripod
Full details and specification for hand winch to be used with the aluminium tripod, SWL 180kg. 20 metre of cable x 6.3mm diameter.(approx. 0.3Mb)
NOTE: Pricing and specifications may be subject to change without notice. Prices shown may be UK only prices and therefore export pricing may vary dependant on location.
Images are for display purposes only.
